TP-LINK TL-SM311LS V5 MiniGBIC Module
Product Code:
TL-SM311LS
18,00 €
(Includes VAT 24%)
Sales price without VAT:
14,52 €
Available
TP-LINK TL-SM311LS V5 MiniGBIC Module
Shipping cost calculation:
Quantity
Description
Characteristics
Downloads
Description
| • Up to 20 km transmission distance in 9/125 μm SMF (Single-Mode Fiber) • Supports Digital Diagnostic Monitoring (DDM) • Compatible with Small Form Pluggable Multi-Source Agreement (SFP-MSA) • Hot-Pluggable with maximum flexibility • Commercial Product Operating Temperature Range: 0-70°C |
What This Product Does
The SM311LS (TL-SM311LS) Fiber Module Cards are introduced to extend transferring distance. Installed in our managed/smart switches, they can extend the distance to even tens of kilometers, which basically satisfy the distance requirement of LAN. Users can choose the fiber modules according to specific demands.
Characteristics
| SPECIFICATIONS | |
| Standards and Protocols | IEEE 802.3z, TCP/IP |
| Wave Length | 1310 nm |
| Dimensions (W*D*H) | 55.4*14.6*12.9 mm |
| Power Supply | 3.3V |
| Safety & Emission | FCC, CE |
| Cabel | Single-Mode Fiber |
| Fiber Type | 9/125 μm Single-Mode |
| Max. Cable Length | 20 KM |
| Data Rate | 1.25Gbps |
| Port Type | LC Duplex |
| Hardware Features | • DDM • SFP-MSA • Hot Swappable |
| Package Contents | • SFP Module SM311LS (TL-SM311LS) • Installation Guide |
| Environment | Operating Temperature: 0–70 °C Storage Temperature: -40–85 °C Operating Humidity: 10–90% RH, Non-Condensing Storage Humidity: 5–90% RH, Non-Condensing |
