Ubiquiti UACC-PΟE++-10G 10Gigabit POE Adapter 54V, 60W
Product Code:
UACC-POE++-10G
50,00 €
(Includes VAT 24%)
Sales price without VAT:
40,32 €
Available
Ubiquiti UACC-PΟE++-10G 10Gigabit POE Adapter 54V, 60W
Shipping cost calculation:
Quantity
Category:
Manufacturer:
Description
Characteristics
Downloads
Description
Ubiquiti UACC-PoE++-10G is an adapter that can power UniFi PoE++ devices, reduce dependency on PoE switch power, and provide a Multi-Gigabit LAN connection.
• Delivers up to 60W of PoE++
• Surge, peak pulse, and overcurrent protection
• LED indicator for status monitoring
Compatibility
• E7, E7-Campus, E7-Audience
Package contents
• 10GE PoE++ adapter
• Wall mount bracket
• AC power cord
• (2) Screws and wall plugs
| Warranties - Returns: | |
| Money Return: | Repair - Replacement: |
| 20 days | 24 months |
Characteristics
| Specifications | |
| Dimensions | 106 x 63 x 34 mm |
| Weight | 210 g |
| Output Voltage | 54V DC @ 1.12A |
| Gigabit LAN Port | Yes |
| Rated Voltage | 100-240VAC @ 50/60Hz |
| Input Current | 1.5A Max. |
| Inrush Current | <150A peak @ 230V AC |
| Efficiency | >88% |
| Output Ripple | 1% max. |
| Switching Frequency | 65 kHz |
| Line Regulation | ≤ 2% |
| Load Regulation | ≤ 5% |
| 4-pair powering | Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-) |
| AC Connector | IEC-320 C6 |
| Data IN / POE | RJ45 Shielded Socket |
| Surge Protection | Difference and Common Mode |
| Clamping Protection | 11V Data, 60V Power |
| Max. Surge Discharge | 1500A (8/20 µs) Power |
| Peak Pulse Current | 36A (10/1000 µs) Data |
| Shunt capacitance | <5 pF data |
| Response time | <1 ns |
| Max. PoE+ wattage per port by PSE | 60W |
| Operating temperature | 0 to 40° C |
| Storage temperature | -30 to 70°C |
| Operating humidity | 10 to 95% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC, UL, UKCA, KC, CCC, KC, RoHS |
