TP-LINK ES228GMP V1.2 Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+
|
• 26× 10/100/1000Mbps RJ45 ports (24× 802.3af/at-compliant PoE+) |
Power over Ethernet, Flexible Network Deployment
Transmit both data and power via a single cable to other 802.3af PoE or 802.3at PoE+ devices, without the hassle and cost of installing power cabling. Automatically detect and supply the required power to PoE-enabled devices.
Works with Omada Central Essentials for Free and Easy Cloud Management
Omada Central Essentials provides free and easy-to-use cloud centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.
Cost-Performance Solution
• Lifetime Free Cloud without Additional Fees
• Manage and Maintain from Anywhere
Multiple Application Scenarios
• Surveillance - Works with IP Cameras
• Wi-Fi Coverage - Works with Access Points
• Conference Calls - Works with IP Phones
• Wired Connections - Works with Non-PoE Devices such as PCs and Printers
§The Omada Cloud-Based Controller offers the Essentials version of cloud services for free, while the Standard version, which includes advanced features, requires a license.
†These functions require the use of the Omada Controller. Zero-Touch Provisioning requires the use of the Omada Cloud-Based Controller (Omada Cloud Standard or Omada Cloud Essentials). Go to the Omada Cloud-Based Controller (Omada Cloud Standard) Product List or Omada Cloud Essentials Product List to find all the supported models.
‡This switch supports PoE Auto Recovery under Standalone Mode (managed separately without a controller) and supports manual PoE Recovery under Controller Mode (centrally managed with a controller).
△QoS and Priority Mode are supported under Standalone Mode.
*PoE budget calculations are based on laboratory testing. The actual PoE power budget is not guaranteed and will vary due to client limitations and environmental factors.
**The speed of the ports that support 820ft PoE transmission will be downgraded to 10 Mbps. Actual transmission distance may vary depending on the quality of the cables.
| Hardware Features & Performance | |
| General | |
| Interface | 24× 10/100/1000 Mbps PoE+ RJ45 Ports 2× 10/100/1000 Mbps RJ45 Ports 2× Gigabit SFP Ports |
| Flash | 64 Mbit |
| Port Standard | IEEE 802.3: Ethernet Media Access Control (MAC) Protocol IEEE 802.3i:10BASE-T Ethernet IEEE 802.3u:100BASE-X Fast Ethernet IEEE 802.3ab:1000BASE-T Gigabit Ethernet IEEE 802.3z:1000BASE-X Gigabit Ethernet (Optical Fiber) IEEE 802.3x: Flow Control IEEE 802.1p: Traffic Class Expediting and Dynamic Multicast Filtering IEEE 802.1q: Virtual Bridged Local Area Networks IEEE 802.1ab: Station and Media Access Control Connectivity Discovery (LLDP) |
| PoE | |
| PoE Standard | 802.3af/at |
| PoE Ports | 24, up to 30 W per port |
| PoE Power Budget | 384 W |
| Fast PoE | YES |
| Perpetual PoE | YES |
| Performance | |
| Switching Capacity | 56 Gbps |
| Packet Forwarding Rate | 41.66 Mpps |
| MAC Address Table | 8K |
| Packet Buffer | 4 Mbit |
| Transmission Method | Store and Forward |
| Jumbo Frame | 15 KB |
| Physical & Environment | |
| Power Supply | 100-240V ~ 50/60Hz |
| Standby Power Consumption | 17.2 W (110V/60 Hz) |
| Max Power Consumption | 454.8 W (110V/60Hz) (with 384 W PD connected) |
| Max Heat Dissipation | 1546.15 BTU/hr (110 V/60 Hz) (with 384 W PD connected) |
| MTBF | 224143h @ 25°C |
| Dimensions (W x D x H) |
440×330×44 mm |
| Net Weight | 5.0 kg |
| Fan Quantity | 2 |
| Dimensions (W x D x H) | 440×180×44 mm |
| Noise | Min: 36.9 dBA @ 1m 25 °C Max: 46.2 dBA @ 1m 25 °C |
| Installation | Desktop/Rackmount Installation |
| Operating Temperature | -5 °C to 45 °C |
| Storage Temperature | -40 °C to 70 °C |
| Operation Humidity | 10% to 90% RH, non-condensing |
| Storage Humidity | 5% to 90% RH, non-condensing |
| Surge Protection | ±6 kV in common mode for Ethernet Ports |
| ESD Protection | Air: ±8 kV, Contact: ±4 kV |
| Certification | CE, FCC, RoHS |
