Grandstream GWN7700M Unmanaged 2.5G Multi-Gigabit Network Switch
Product Code:
GWN7700M
57,00 €
(Includes VAT 24%)
Sales price without VAT:
45,97 €
Available
Grandstream GWN7700M Unmanaged 2.5G Multi-Gigabit Network Switch
Shipping cost calculation:
Quantity
Description
Characteristics
Downloads
Description
The GWN7700M series are 6 & 9 port unmanaged multi-Gigabit network switches that provide high-speed network connectivity up to 2.5Gbps to home offices and small-to-medium businesses.
Features:
• 5 and 8 Multi-Gigabit Copper Ports provide 100/1000/2500Mbps connectivity
• One SFP+ Fiber Port with 1 Gigabit or 10-Gigabit connectivity
• LED Indicators; Per port: Link/Activity/Speed Per device: Power
• Auto MDI/MDIX crossover for all ports
• Whisper Quiet: fanless
• Broadcast/Multicast/Unicast Storm Control (fixed to 100Mbps) to monitor traffic levels
• Green technology reduces power consumption
• QoS - Supports Default Strict Priority when present
Characteristics
| Specifications | |
| Gigabit Ports | 5 |
| Enclosure | Metal |
| Mounting | Desktop/ Wall-Mount |
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz(2.5GBASE-T), IEEE 802.3x, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3aq |
| Port Feature | 5× 100/1000/2500Mbps RJ45 Ports 1× SFP+ Fiber Port AUTO Negotiation AUTO MDI/MDIX |
| Network Media | 2.5GBase-T / 1000Base-T / 100Base-TX / 10 Base-Te, Half/Full-Duplex |
| LED Indicators | Per port: Link/Activity Green Per device: Power Green |
| Mac Address Table | 4K |
| Switching Capacity | 45Gbps |
| Jumbo Frame | 9KB |
| Advanced Features | Mac Address Auto-Learning And Auto-Aging IEEE 802.3x Flow Control IEEE 802.3az (Energy Efficient Ethernet) 802.1p/DSCP QoS IGMP: •IGMP Fast-Leave •IGMP Snoop •Route Port Autolearn •Query Refresh Member Port |
| Power Adapter | External 12VDC/1A |
| Max Power Consumption by Base System | 7.0W |
| Environmental | Operating Temperature: 0 to 40 °C Storage Temperature: -20 to 60 °C Operating Humidity: 10% to 90% Non-condensing Storage Humidity: 10% to 90% Non-condensing |
| Dimensions (L x W x H) | Unit: 145 x 80 x 27mm Package: 255 x 110 x 53mm |
| Weight | Unit Weight: 0.3KG Entire Package: 0.52KG |
| Package | 1x Switch, 1x Power Adapter,1x QIG |
| Compliance | FCC, CE, RCM, IC, UKCA |
