TP-LINK EAP653 UR V2 AX3000 Ceiling Mount Wi-Fi 6 Access Point
CAUTION!!! Package doesn't include Power Adapter!!!
| • Ultra-Fast WiFi 6 Speeds: 402 Mbps on 5 GHz t+ 574 Mbps on 2.4 GHz† • Ultra-range wireless coverage by more antennas with higher transmit power • Supports WiFi 6 technologies, such as HE160, 1024-QAM, etc‡ • Advanced Features: Omada Mesh, Seamless Roaming, etc§ • PoE+ Powered: Supports both 802.3at PoE+ and DC (adapter not included) • Ultra-Slim Design: Φ6.3 in × 1.3 in elegant design brings more agility • Integrates with the Omada SDN platform for centralized management |
Ultra-Range Wireless Coverage
More antennas with high transmission power offer robust and extensive wireless coverage. Always have full coverage for your office.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.
‡Use of WiFi 6 (802.11ax) and its features, including OFDMA, HE160, and 1024-QAM, require clients to support the corresponding features. The 160 MHz bandwidth is only available on the 5 GHz band. It may be unavailable in some regions/countries due to regulatory restrictions. The double channel width refers to 160 MHz compared to 80 MHz for general WiFi 6 APs.
§Omada Mesh, Seamless Roaming, Captive Portal, and Cloud Access require the use of Omada SDN controllers. Go to https://www.tp-link.com/en/omada-mesh/product-list/ to find all the models supported by Omada mesh technology to find all the models supported by Omada mesh technology, and refer to the User Guides of Omada SDN controllers for configuration methods.
*Zero-Touch Provisioning and Auto Channel Selection and Power Adjustment require the use of Omada Cloud-Based Controller. Go to https://www.tp-link.com/en/omada-cloud-based-controller/product-list/ to confirm which models are compatible with Omada Cloud-Based Controller.
**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
***Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.
| HARDWARE FEATURES | |
| Main Design | |
| Interfaces | 1 x 10M/100M/1000M Multigigabit Ethernet Port (RJ45); PoE in 1 x DC power interface: 12VDC |
| IoT | BLE5.2,1Mbps |
| Memory | Flash: 1Gbit DRAM: 4Gbit |
| Button | 1 × Reset button: Press the button for longer than 5 seconds to make the device restore to factory settings. |
| Indicator | 1 × single-color system LED indicates on the front: •Power-on status •Firmware initialization or upgrade status •Uplink service status •Error status |
| Reliability | MTBF (Mean Time between Failure) - 356042H@25°C, 164280H@40°C |
| Power Supply | Input - •48V Passive POE or 802.3at POE •DC: 12V/1.5A |
| Power Consumption |
14.2W, 2.4GHz radio 2×2, 5GHz radio 2×2. |
| Surge/Lightning Protection | Ethernet Ports: ±4 kV |
| ESD/EMP Protection | •Air discharge: ±8 kV •Contact discharge: ±4 kV |
| Maximum transmit power |
CE(EIRP) FCC (conducted power) |
| Minimum transmit power |
CE(EIRP) FCC (conducted power) |
| Adjustable power increment |
1 dB |
| Environment |
Environment - Humidity - Altitude - |
| Unit |
Dimensions (W×D×H) - Weight - Mounting - |
Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.
Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5150 – 5250MHz and 5250 – 5350MHz, provides for a maximum transmit power of 200 mW e.i.r.p. and in the frequency band 5470 – 5725MHz, provides for a maximum transmit power of 1 W e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.
