| • Cutting-edge 4G network – share internet access with up to 32 Wi-Fi devices and enjoy download speeds of up to 150 Mbps • Plug a SIM card and play – no configurations needed, compatibility of SIM cards in 100+ countries are assured by years of field tests • Two detachable advanced LTE antennas – enjoy stable and efficient connections to every device thanks to the two external antennas • Wi-Fi router mode – plug an Ethernet cable into the LAN/WAN port for flexible access if you can't get a 4G connection |
No Configuration Needed Simply Plug and Play!
With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do is insert the Nano SIM card and turn on the router. Enjoying fast, stable Wi-Fi on a 4G LTE network has never been easier.
Share Your 4G LTE Network
Take full of advantage of your cutting-edge 4G LTE network for download speeds of up to 150 Mbps. Share your 4G LTE network with multiple Wi-Fi devices and enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. Fully compatible with FDD-LTE and TDD-LTE to work with most service providers worldwide.
Wi-Fi Where You Need It
Enjoy unmatched convenience and versatility. Tested in the field for years to ensure universal compatibility with 2 advanced LTE antennas to deliver a smooth connection. Simply plug in a Nano SIM card and power on this elegant piece of technology to utilize fast and stable Wi-Fi, whether you’re at home or working remote.
Internet Access for up to 32 Devices simultaneously
Easily share a 3G/4G connection with up to 32 wireless devices, such as phones, tablets, and laptops, at the same time. 4 LAN ports stand ready to provide internet for wired devices like desktop computers.
Available WAN Connection
The WAN/LAN port enables Archer TL-MR6400 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems. And when it's set as a wireless router, its 3G/4G connection works as a backup to provide a sustained and reliable internet connection for you.
Easy Setup and Management
Set up the TL-MR6400 in minutes thanks to its intuitive web interface and the powrful Tether app. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and access control.
|
Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p. |
| Specifications | |
| Hardware | |
| Ports | 3 10/100 Mbps LAN ports, 1 10/100 Mbps LAN/WAN Port, 1 Nano SIM Card Slot |
| Button | WPS/RESET Button, WiFi ON/OFF Button |
| Antenna | 2 × Detachable External 4G LTE Antennas |
| External Power Supply | 9V/0.85A |
| Dimensions (W x D x H) | 174 × 124.5 × 33.5 mm |
| Wireless | |
| Network Type | 4G: FDD-LTE:B1/B3/B7/B8/B20(2100/1800/2600/900/800 MHz) TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz) 3G: DC-HSPA+/HSPA/UMTS:B1/B8(2100/900 MHz) |
| Wireless Standards | IEEE 802.11b, 802.11g, 802.11n |
| Frequency | 2.4 GHz |
| Signal Rate | 300 Mbps at 2.4 GHz |
| EIRP (CE) | < 20 dBm (2.4 GHz) |
| Reception Sensitivity | 11g 54M: -74 dBm 11n HT20: -71 dBm 11n HT40: -67 dBm |
| Wireless Function | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions |
| Software | |
| Operating Modes | 3G/4G Router, Wireless Router |
| Management | Access Control, Local Management, Remote Management |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Firewall Security | DoS Protection, SPI Firewall, IP and MAC Address Binding |
| DHCP | Server, Client, DHCP Client List, Address Reservation |
| VPN Passthrough | PPTP, L2TP, IPSec |
| VPN Server | PPTP VPN, OpenVPN |
| Port Forwarding | ALG, Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | TP-Link DDNS, DynDns, NO-IP |
| Security | IPv4 SPI Firewall, IP and MAC Address Binding |
| Protocols | IPv4, IPv6 |
| Administration | Upgrade Firmware, Factory Default, System Log, Diagnostic Tools |
| Guest Network | 2.4 GHz Guest Network |
| OTHERS | |
| Certification | CE, RoHS |
| Package Contents | 300Mbps Wireless N 4G LTE Router TL-MR6400 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
| Requirements | Edge, Firefox, Chrome, Safari, or other JavaScript-enabled browser *You are recommended to use the latest version Nano SIM Card |
| Environment | Operating Temperature: 0℃~40℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
