MikroTik LHG-5AXD, RouterBoard LHG 5 AX
MikroTik LHG-5AXD, RouterBoard LHG 5 AX
Need a fast, stable connection across large distances? Whether you’re bridging two buildings, connecting a remote site, or sharing your internet with nearby infrastructure — the new LHG Wi-Fi 6 series is built for the challenge. And here’s the best part: we’ve kept the same pricing as the previous generation. High performance, long range, and Wi-Fi 6 — all without breaking the budget.
The 802.11ax standard brings crucial improvements for long-distance wireless links — including better spectral efficiency, higher modulation rates (1024-QAM), and lower latency. That means stronger performance even in noisy environments and faster, more stable connections over a greater distance. Combined with WPA3 encryption and RouterOS v7, the LHG ax series is ready for the challenges of modern outdoor networking. Order yours today — and be ready too!
LHG 5 ax is compact, long-range CPE with a 24.5 dBi antenna. Perfect for links up to 20 km in most scenarios.
| Specifications | |
| Product code | LHG-5axD |
| CPU | Dual-Core IPQ-5010 800 MHz |
| CPU architecture | ARM 64bit |
| Size of RAM | 256 MB |
| Storage | 128 MB, NAND |
| Number of 1G Ethernet ports | 1 |
| Wireless interface model | QCN-6102 |
| Wireless | 5 GHz 802.11a/n/ac/ax |
| Antenna gain | 24.5 dBi |
| Dimensions | 391 x 222 mm |
| Operating system | RouterOS v7, License level 3 |
| Operating temparature | -40°C to +70°C |
| Powering | |
| DC input | PoE-In |
| Input Voltage | 12-28 V |
| Power adapter nominal voltage | 24 V |
| Power adapter nominal current | 0.38 A |
| PoE-In | Passive PoE |
| Max power consumption | 5 W |
| Included parts |
• 24 V 0.38 A power adapter |
Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5150 – 5250MHz and 5250 – 5350MHz, provides for a maximum transmit power of 200 mW e.i.r.p. and in the frequency band 5470 – 5725MHz, provides for a maximum transmit power of 1 W e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for outdoor use.
