MaxLink 01-VS-M12 Omnidirectional antenna 2.4GHz 12dBi
Κωδικός προϊόντος:
01-VS-M12
33,50 €
(Περιλαμβάνει ΦΠΑ 24%)
Τιμή χωρίς ΦΠΑ:
27,02 €
7 Ημέρες
MaxLink 01-VS-M12 Omnidirectional antenna 2.4GHz 12dBi
Υπολογισμός κόστους μεταφορικών:
Ποσότητα
Περιγραφή
Χαρακτηριστικά
Περιγραφή
Omnidirectional antenna with a gain of 12 dBi, outdoor design, vertical polarization and use in the band 2.4 GHz (2400 ~ 2483 MHz). Ideal for use on shorter distances such as WiFi, Bluetooth, RFID, etc. The antenna is terminated with an N-male connector.
Package includes
• Device
• Mast holder
• (2) Cable tie
Χαρακτηριστικά
| Specifications | |
| MIMO, SISO | 1 x 1 |
| Polarization | V |
| VSWR | < 1,5 |
| Wireless frequency | 2.4 GHz |
| Elevation beam width (-6dB) | 8° |
| Azimuth beam width (-6dB) | 360° |
| Antenna type | Omnidirectional |
| Antenna gain | 12dBi |
| RF connectors | (1) N male |
| Wind load | 240km/h |
| Purpose | Outdoor |
| Material | Fiberglass |
| Weight | 0.25kg |
| Width | 19mm |
| Height | 1100mm |
| Depth | 19mm |
