AJAX SYSTEMS AJ-KEYPAD-TSC-W - KEYPAD TOUCHSCREEN WHITE

Κωδικός προϊόντος:
AJ-KEYPAD-TSC-W
Άμεσα διαθέσιμο
AJAX SYSTEMS AJ-KEYPAD-TSC-W - KEYPAD TOUCHSCREEN WHITE
Υπολογισμός κόστους μεταφορικών:
Καλέστε για τιμή
Κατηγορία:
Κατασκευαστής:
Εγγύηση:
24 Μήνες
Περιγραφή
Χαρακτηριστικά
Λήψεις
Νομική Σημείωση
Περιγραφή
• Auto screen wake up and brightness adjustment
• Easy group management
• Malfunction reports when arming the system
• Alarms and events with sound indication

Convenient Ajax system control
KeyPad TouchScreen combines security and smart home device management. An intuitive Ajax app-like interface and multiple language options make it an easy-to-use solution. The big display, DESFire and BLE technologies, and code options ensure a secure and efficient experience.

One device, three missions
1) Security Management -
Easily manage security for multiple groups. Users can view what's armed and make changes with just one touch whether it's securing one group, multiple groups, activating night mode, or arming facility. It's all simple and straightforward.
• Easy group management
• Security mode of each group is available on the screen
• Management of night mode and security mode of the entire system

2) Smart home control -
The keypad features a separate control tab for automation devices, with the capacity for up to 6 buttons. Groups simplify the process of controlling multiple automation devices: switches, relays, sockets, and others. For instance, users can assign all LightSwitches to one button and easily turn off all the lights in the entire house when they go to bed.
• Separate tab for automation control
• Up to 6 devices or groups of devices on one screen

3) Smart and malfunction notifications - Stay always informed with the built-in buzzer, receiving notifications about alarms, door openings, and entry/exit delays. PRO can effortlessly adjust the sound volume on a smartphone or PC. Remain one step ahead with the keypad's malfunction notifications during arming.
• Sound notifications about alarms and events
• Instant malfunction notifications

Easy group management
Security mode of each group is available on the screen
Management of night mode and security mode of the entire system

Three authentication methods
There are three easy ways to control the keypad, giving users the flexibility to choose what suits them best. All events display in the feed, including user activity and authentication details.

Contactless access devices
The Pass card and the Tag key fob are equipped with original DESFire® chips and feature the same functionality but different enclosures. You can choose the form that is convenient for you. One Tag or Pass can control 13 security systems. Access devices are sold separately in batches of 3/10/100 pieces.

Access for unregistered users
With a simple assignment of a personal access code in the hub settings, office employees, cleaning company staff, or other individuals enter the area with convenience at its finest.

Full protection in case of emergency
KeyPad TouchScreen provides a tab with configurable panic buttons that can notify about three event types. If the user is forced to disarm the system, they can use a duress code. It simulates disarming and simultaneously sends an alarm to the security company.

Unique touch screen operation experience
A high-resolution screen accommodates all necessary controls, ensuring a visually stunning and high-quality image. With automatic brightness adjustment and sleek glass material, the product offers aesthetics and convenience.
• 5-inch screen with a resolution of 480 × 854 px
• Bright during the day, not dazzling at night
• Screen protection against scrapes, scratches, etc.



Χαρακτηριστικά
Technical specifications
Compatibility
Control panels Hub 2 (2G) / Hub 2 (4G) / Hub 2 Plus /
Hub Hybrid (2G) / Hub Hybrid (4G) / Differences between hubs
Range extenders ReX 2
Communication
Communication technology Jeweller: Proprietary wireless communication technology to transmit commands, alarms, and events.
Wings: Proprietary wireless communication technology for transmitting the list of the groups, rooms and detectors to form the list of malfunctions.
Maximum effective radiated power (ERP)
(Jeweller)
up to 20 mW
Radio signal range
(Jeweller / Wings)
up to 1,700 m
Between keypad and hub (or range extender) in an open space.
Encrypted communication
(Jeweller / Wings)
All the data stored and transmitted are protected by block encryption with a dynamic key.
Frequency hopping
(Jeweller / Wings)
Radio communication uses frequency hopping to prevent interception and jamming.
Display
Diagonal 5″
Matrix type IPS
Resolution 480 × 854 px
Sensor capacitive
Brightness settings • automatic
• manual
Backlight lifetime 30,000 hours
Sabotage protection • Unauthorized access auto-lock
• Tamper alarm
• Holding screw
• Protection against spoofing
• Communication loss detection
Power supply
Batteries 6 × AA
Calculated battery life up to 1.5 years
Keypad’s operating voltage range 10.5–14 V⎓, up to 0.4 A
Keypad’s nominal operating voltage 12 V⎓
Enclosure
Dimensions 172 × 82 × 26 mm
Weight 327 g
Operating temperature range from -10°C to +40°C
Operating humidity up to 75%
Package contents
KeyPad TouchScreen
SmartBracket mounting panel
6 АА batteries (pre-installed)
Installation kit
Quick start guide
Λήψεις
Νομική Σημείωση

Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 863 – 870 MHz, προβλέπει μέγιστη ισχύ εκπομπής όπως περιγράφεται στην απαίτηση διεπαφής ραδιοεξοπλισμού 105. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς και εξωτερικούς χώρους.
