Hikvision DS-K1T105AM Pro Series Card Terminal
• IP addresses conflicted alarm
• Supports communicating with 4 control clients simultaneously; Supports uploading real-time events
• Gets offline events: Avoids events losing
• Touch mode and blue light display technique for keypad
• Stand-alone settings for the terminal
• 2.8-inch LCD display screen to display the time, the date, etc.
• Max. 100,000 valid card capacity, and Max. 300,000 access control events capacity
• Communication via wired network (TCP/TP) and Wi-Fi
• Supports ISUP protocol for public network communication
• Supports multiple door opening modes (card, card + password, exit button, etc.)
• Supports RS-485 and Wiegand (26/34) communication for connecting the external card reader
• Applies authentications from the client to the device
• Supports working as a card reader, and supports Wiegand (26/34) interface and RS-485 interface for accessing the controller
• Supports Mifare card reading
• M1 card encryption
• Tampering detection, unlocking overtime alarm, invalid card presenting over times alarm, forced opening door alarm, and duress card alarm
• Creates dismiss code for dismiss alarm
• Accurate data and time display provided by built-in electronic clock and watchdog program to ensure the basic function of the terminal
• Data can be permanently saved after power-off
| Specifications | |
| Operating System | Linux |
| Screen | |
| Size | 2.8-inch |
| Resolution | 320 × 240 |
| Type | Display screen |
| Audio | |
| Audio output | Loudspeaker |
| Network | |
| Wired network | 100 M/1000 M self-adaptive |
| Wi-Fi | Support |
| Communication protocol | TCP/IP |
| Interface | |
| Network interface | 1 |
| RS-485 | 1 |
| Wiegand | 1 |
| Lock output | 1 |
| Exit button | 1 |
| Door contact input | 1 |
| IO input | 2 |
| IO output | 1 |
| TAMPER | 1 |
| USB | 1 |
| Capacity | |
| Card capacity | 100,000 |
| Event capacity | 300,000 |
| Authentication | |
| Card reading distance | ＜ 1 s |
| Card reading duration | 0 to 5 cm |
| Others | |
| Power supply | 12 VDC/2 A |
| Working temperature | -30 °C to 60 °C |
| Working humidity | 10% to 90% |
| Dimensions | 137 mm x 142 mm x 35 mm |
