Grandstream GDS3726 Smart IP Video Door Station
Grandstream GDS3726 Smart IP Video Door Station
Combining a sleek, modern aesthetic with industrial-grade durability, the GDS3720 Smart IP Video Door Station series delivers an all-in-one solution for access control, intercom, and security protection. Their versatile port array and PoE support allow you to seamlessly unify terminal devices into a single, cohesive security network. Packed with integrated BLE 5.0 and native support for major protocols like ONVIF, SIP, and RTSP, the GDS3720 series easily scales to provide tailored, rock-solid security for schools, residential communities, and commercial or industrial complexes.
Features:
• Real-time AI-based behavior analysis enables instant event detection and alarm triggering
• Features a 2K Ultra HD camera, WDR, and smart AI fill light for flawless visibility in any lighting.
• Built-in Solid State Relay (SSR) provides robust protection against external magnetic interference.
• Experience ultimate convenience with flexible entry options, including IC/ID cards, NFC, Bluetooth, mobile app, QR codes, and SIP calling.
• Engineered to withstand the harshest environments with a certified IP66 rating.
• The GDS3726(Q) features maximum IK10-rated impact resistance across the entire unit, including the lens areas.
• This series delivers true hybrid flexibility, seamlessly balancing local web UI control with GDS Manager desktop software, GDMS, and SecureAccess app, along with seamless compatibility with Home Assistant.
• Seamlessly fit into existing systems with standard ONVIF protocol support, ensuring maximum flexibility and universal compatibility.
| Technical Specifications | |
| Basic | |
| Unit Dimension | 204 mm × 87 mm × 35.5 mm (H × W × D) |
| Package Dimension | 255 mm × 130 mm × 88 mm |
| Unit Weight | 1.55 kg |
| Package Weight | 1.733 kg |
| Installation Methods | Wall Mount, Flush Mount (Solid Wall, Dry Wall, Stud) |
| Ports | |
| Network Port | 1 × 10/100 Mbps PoE Ethernet port |
| Alarm Input | 3 channels |
| Relay Output | 2-channel outputs for both lock control and alarm linkage: An antimagnetic Solid State Relay (SSR) for alarm linkage and high security lock control |
| RS-485 | 1 port |
| Wiegand Port | 1-channel Wiegand port (26/34/58-bit), 6-pin interface (WG_D0, WG_D1, GND, WG_BEEP, WG_LED, 5V_WG) |
| Grounding | 2 × GND ports |
| TF Card Slot | 1 × slot (up to 256 GB) |
| RFID | |
| Card Type | IC Card (13.56 MHz) and ID Card (125 kHz) |
| RFID | Supports MIFARE Classic 1K, MIFARE Classic 4K, MIFARE Ultralight, MIFARE PLUS and MIFARE DESFire |
| Connectivity | |
| Bluetooth | BLE 5.0 |
| Button | |
| Keys | 1 × Doorbell Key |
| Security | 1 × Tamper Switch |
| Maintenance | 1 × Reset Button |
| LEDs | |
| Fill Light | 6 × White LEDs |
| System Indicator | 1 × Multi-Color LED (Red, Green, Blue, White) |
| Card Reading | 1 × White LED |
| Key Backlight | 1 × Green key LED |
| Power | |
| Power Supply | 9–36 V DC, 12 W |
| PoE Standard | 802.3af Class3 |
| Audio | |
| Microphone | 2 microphones |
| Speaker | 3 W |
| Video | |
| Image Sensor | 1/3, 4 MP with HDR support |
| Lens | F2.2 |
| Field of View | H: 127°; V: 70°; D: 152° |
| Max Resolution | 1920 × 1080 |
| Max Frame Rate | 30 frames per second |
| Wide Dynamic Range (WDR) |
Supported, up to 120 dB |
| Video Analytics | AI-Based Motion Detection |
| Light Supplement | Auto-brightness white light |
| PIR Detection | Supported, 3–5 m |
| Environmental Endurance | |
| Operating Temperature |
-30 °C to 60 °C |
| Storage Temperature | -30 °C to 70 °C |
| Operating Humidity | 10%–90%, non-condensing |
| Storage Humidity | 10%–90%, non-condensing |
| Certification | |
| Protection Rating | • IP66 • IK10 for metal surface, buttons and lens area |
| Compliance | FCC, CE, RCM, IC |
| Package Contents | |
| Primary Unit | 1 × Door Station |
| Manual and License | 1 × Quick Installation Guide 1 × Certification Regulatory Information |
| Installation Accessories |
1 × Screwdriver 1 × Wall Mounting Position Sticker 1 × Wall Mounting Bracket 1 × Terminal Block Back Panel 7 × Expansion Bolts 7 × Pan Head Tapping Screws (ST3.5 × 32 mm) 2 × Pan Head Machine Screws (M3 × 5.5 mm) 2 × Pan Head Hexalobular Socket Machine Screws (M3 × 6 mm) 2 × Waterproof Silicone Plugs 1 × Waterproof Plug Washer |
| Other Accessories | 1 × IC Card (Mifare Classic EV1) |
