Ubiquiti USW-Aggregation UniFi Switch Aggregation
Κωδικός προϊόντος:
USW-AGGREGATION
Περιγραφή
Χαρακτηριστικά
Λήψεις
Περιγραφή
| • (8) 10G SFP+ Ports • 160 Gbps switching capacity • 1.3" Touchscreen with AR switch management • Fanless, 4.7" depth compact enclosure • 1U Rackmountable (kit included) • Managed by UniFi Network Controller Managed by UniFi Network Controller version: 5.14.12 or higher. |
UniFi Aggregation Switch is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7" depth and fanless design, it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.
Works with UniFi Network Controller
• Manage Your Networks from a Single Control Plane
• Intuitive and Robust Configuration, Control and Monitoring
• Remote Firmware Upgrade
• Users and Guests
• Guest Portal/Hotspot Support
Χαρακτηριστικά
| Specifications | |
| Mechanical | |
| Dimensions | 442.4 x 120 x 43.7 mm |
| Weight | Without Mount: 2.65 kg With Mount: 2.74 kg |
| Enclosure Material | SGCC Steel |
| Hardware | |
| Total Non-Blocking Line Rate | 80 Gbps |
| Switching Capacity | 160 Gbps |
| Forwarding Rate | 119.04 Mpps |
| Max. Power Consumption | 30W |
| Power Method | Universal AC Input: 100-240VAC, 50/60 Hz |
| Power Supply | AC/DC, Internal, 36W |
| Management Interface | Ethernet In-Band |
| Modes | SMB Layer 2 Gigabit Ethernet Switch |
| ESD/EMP Protection | Air: ± 16kV, Contact: ± 12kV |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
| LED | |
| System (1) Bootup Animation Firmware Upgrade Icon Steady White Steady Blue SFP+ |
Bootup in Progress Firmware Upgrading Factory Defaults, Awaiting Adoption Device is Adopted White: 10G, 1G |
