TP-LINK TL-SF1008P V7 8-Port 10/100Mbps Desktop Switch with 4-Port PoE+
| • 8x 10/100 Mbps RJ45 ports • 4x PoE+ ports transfer data and power on individual cables • Works with IEEE 802.3af/at compliant PDs • Supports PoE Power up to 30 W for each PoE port • Supports PoE Power up to 66 W for all PoE ports* • Up to 250m data and power transmitting range under Extend Mode** • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application • PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices • Fanless Design reduces power consumption and works silently in its location • Plug and play with no configuration required |
Dedicated 8-Port Switch with 4-Port PoE+ (66 W Budget) for Numerous Applications
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 66 W PoE power budget* for the 4x PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.
Plug and Play, No Configuration Required
1) Plug In
2) Connect Devices
3) Enjoy
Dedicated Design for IP Surveillance — Up to 250 m Transmissions
With extend mode, the PoE transmission distance reaches up to 250 m*—perfect for IP Camera deployment in large areas.
*The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.
Priority Video Quality Guaranteed
Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.
System Self-Healing with PoE Auto Recovery
The switch automatically detects and reboots the PD devices, such as cameras and APs, when they fall offline or go unresponsive, guaranteeing the stable operation of PoE-connected devices, without need for manual monitoring and restart.
Intelligent Power Management
When total power consumption exceeds 66 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.
Durable Metal Casing
The interior components of TL-SF1008P are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1008P delivers switching performance you can depend on.
*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.
**The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.
| SPECIFICATIONS | |
| Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| Network Ports | 8 x 10/100 Mbps RJ45 ports with 4 PoE+ ports (port 1 to port 4) |
| Network Media (Cable) | 10Base-T: UTP category 3, 4, 5 cable (maximum 100 m) EIA/TIA-568 100 Ω STP (maximum 100 m) 100Base-TX: UTP category 5, 5e cable (maximum 100 m) EIA/TIA-568 100 Ω STP (maximum 100 m) |
| PoE | PoE Standard: IEEE 802.3af, IEEE 802.3at PoE Port 1–4, up to 30 W per port PoE Power Budget 66 W* |
| Auto-Negotiation | YES |
| Auto MDI/MDIX | YES |
| PoE Power on RJ45 | Power+: pin 3 & pin 6 Power -: pin 1 & pin 2 |
| Max Power Consumption | 2.27 W (220 V/50 Hz no PD connected) 73.35 W (220 V/50 Hz with 66 W* PD connected) |
| Max Heat Dissipation | 7.74 BTU/h (220 V/50 Hz no PD connected) 256.88 BTU/h (220 V/50 Hz with 66 W* PD connected) |
| Forwarding Mode | Store and Forward |
| Switch Capacity | 1.6 Gbps |
| MAC Address Table | 2k, Auto-learning, Auto-aging |
| Extend Mode | YES |
| Priority Mode | YES |
| PoE Auto Recovery | YES |
| Flow Control | YES |
| Fanless | YES |
| LED | Power, Link/Act, PoE Status, PoE MAX |
| Dimensions | 171 x 98 x 27 mm |
| Certification | CE, FCC |
| Package Contents | TL-SF1008P Power Adapter Installation Guide Rubber Feet |
