Ubiquiti UA-ULTRA UniFi Access Ultra Hub, Access Reader
Product Code:
UA-ULTRA
131,00 €
(Includes VAT 24%)
Sales price without VAT:
105,65 €
Available
Ubiquiti UA-ULTRA UniFi Access Ultra Hub, Access Reader
Shipping cost calculation:
Quantity
Description
Characteristics
Downloads
Description
CAUTION PACKAGE DOES NOT INCLUDE POE ADAPTER
Ubiquiti Access Ultra is a complete device for locking doors and subsequent control. Unlocking can be done using an NFC card, chip, or phone through UniFi Identity. The locking terminal supports 12V/1A and includes pins for exit. The reader has an IP55 rating and operates in temperatures ranging from -30 to 40 degrees Celsius. Power is supplied via PoE+.
Features:
• (1) Lock terminal (12V/1A)
• (1) Exit request input
• Unlock using an NFC card or UniFi Identity mobile app
• Connect and power using PoE+
• IP55 weather resistance (-30 to 40° C)
Characteristics
| Specifications | |
| Mechanical | |
| Dimensions | 126 x 45 x 37.45 mm |
| Weight | 140 g |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mounting | Wall mount, gang box mount |
| Weatherproofing | IP55 |
| Hardware | |
| Networking Interface | 10/100 MbE RJ45 port |
| Connectivity | Ethernet BLE 4.2 |
| Digital input | (1) Exit request |
| Lock terminals | (1) 12V, 1A |
| Power method | PoE+ |
| Max. power consumption | 18W |
| ESD/EMP protection | Air: ±8kV, contact: ± 4kV |
| LEDs | Steady white: Pending adoption Steady blue: Adopted Alternating white/blue: Firmware updating Strobing red: Emergency lockdown Steady green: Emergency evacuation (2) Rapid flashing blue: NFC credential authenticated (2) Rapid flashing red: NFC credential authentication failed Breathing blue: Ready to register NFC cards |
| Buttons | (1) Factory reset |
| Tamper switch | Yes |
| Speaker | Buzzer |
| NFC frequency | 13.56 Mhz |
| NFC read range | < 50 mm |
| NFC standards | ISO 14443A, 14443B, 15693 |
| NFC technology | NFC Tag 1,2,3,4,5 MIFARE Classic MIFARE Plus Mifare Ultralight MIFARE DESFire |
| Operating Temperature | -30 to 40° C |
| Operating Humidity | 5 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
