Description
• 868 MHz two-way wireless communication
• 3 years battery life span (triggered every two weeks and alerting 90 s for each triggering)
• AES-128 encryption
• Front and rear panel tamper-proof
• 3 kinds of alarm sounds: fire alarm, panic alarm, and intrusion alarm
• Buzzer Decibel: 110 dB
• Fully remote configurable through APP
• Multiple enrollment methods and easy installation design
• Frequency hopping against jamming for reliable transmission
• IP65 protective level
Characteristics
| Technical Specifications | |
| Battery type | Battery (default power supply method) or 12 VDC |
| Power supply | Battery (default power supply method) or 12 VDC |
| Operation humidity | 10% to 90% (no condensing) |
| Operation temperature | -20°C to 60°C |
| Battery life span | Up to 3 years (standby time) |
| Wireless transmission | |
| RF frequency | 868 MHz |
| RF modulation | 2GFSK |
| RF distance | 1.6 km (open area) |
| General | |
| IP rate | IP65 |
| Installation method | Wall-mounting |
| Dimension(WxHxD) | 190 mm × 200 mm × 47. 3mm |
| Shell materia | PC+ABS |
| Weight | 606.5 g |
Downloads
Legal Notice
Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 863 – 870 MHz, provides for a maximum transmit power as described in the radio equipment interface requirement 105. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor and outdoor use.
