Grandstream POE INJECTOR 24W Gigabit PoE 48V-500mA
Product Code:
PoE Injector
26,00 €
(Includes VAT 24%)
Sales price without VAT:
20,97 €
Available
Grandstream POE INJECTOR 24W Gigabit PoE 48V-500mA
Shipping cost calculation:
Quantity
Description
Characteristics
Downloads
Description
This PoE Injector supports Gigabit speeds while offering 1 LAN port, 1 PoE port and output voltage of 48V 0.5A. The device includes an AC power adaptor which requires 24W maximum and offers one LED indicator to visually identify active use.
Features:
• PoE Standard No Detection – passive injector
• Input Power 100-240VAC;50-60Hz 0.75A
• PoE Output Output: 48V0.5A
• Power Consumption 24W max
• LED Indicator AC power; PoE Active
Characteristics
| Specifications | |
| PoE Standard | No Detection – passive injector |
| Input Power | 100-240VAC;50-60Hz 0.75A |
| PoE Output | Output: 48V0.5A |
| Power Consumption | 24W max |
| RJ45 Pin Assignment & Polarity Powers |
Pins 4/5(+), 7/8(-) |
| Data Rate | 10/100/1000Mbps |
| MTBF | 500K Hours |
| Safety Approval | UL/cUL,GS,CB,FCC,CE |
| Efficiency | VI |
| Standards | IEEE 802.3 10Base-T, IEEE 802.3U 100Base-TX, IEEE 802.3ab 1000Base-T |
| LED Indicator | AC power; PoE Active |
| Interface | 1 ’’Data’’ In RJ-45 Ethernet Port 1 ’’Data+Power’’ Output RJ-45 Ethernet Port 1 AC Input Power socket |
| Environmental | |
| Opearting Temperature | 0 to +40 |
| Storage Temperature | -40 to +70 |
| Humidity | 0 to +95 RH |
| Mechanical | |
| Device Weight | 133g |
| Dimensions | 97mm x 53.5mm x 33.5mm 114mm x 53.5mm x 67.5mm (including ear) |
