MikroTik CRS504-4XQ-OUT, Cloud Router Switch, 4x 100 Gigabit ports

Product Code:
CRS504-4XQ-OUT
765,00 €
(Includes VAT 24%)
Sales price without VAT:
616,94 €
Available
MikroTik CRS504-4XQ-OUT, Cloud Router Switch, 4x 100 Gigabit ports
Shipping cost calculation:
Quantity
Add to Cart
Category:
Manufacturer:
Warranty:
12 Months
Description
Characteristics
Downloads
Description



At the core of this masterpiece, they have an incredible Marvell Prestera switch chip. And there are four 100 Gigabit QSFP28 ports. Use them to connect other 100 Gigabit devices or grab a breakout cable to connect multiple 25 Gigabit devices. Here’s where the speedy switch chip really shines: each port is connected to four 25 Gigabit lines. That means you’re getting up to 16 high-speed fiber interfaces from a single outdoor switch! You can mix and match all kinds of connections this way: 100 Gigabits on one port, 40 Gigabits on the other, 4x25 Gigabits on the third, and maybe even some 10G or 1G cables on the fourth. And all this versatility comes in a sturdy, weatherproof IP66-rated enclosure. This rating proves it’s strong enough to handle powerful water jets from any direction!

When it comes to outdoor event planning, you can never be too prepared. So having multiple powering options is a must! And CRS504-4XQ-OUT has got you covered: there’s a standard DC jack, a 2-pin terminal, and 802.3bt PoE-in. They also kept the good old management and console ports – to help you deal with any unexpected situations.

Performance-wise, CRS504-4XQ-OUT is a real workhorse that can handle VLANs, ACL, MLAG, Jumbo frames, and so much more – even some L3 hardware offloading! The mighty Marvell Prestera switch chip dominates most tasks without blowing the power consumption up – only up to 25W (without attachments).



Characteristics
Specifications
Product code CRS504-4XQ-OUT
CPU QCA9531 650 MHz
CPU architecture MIPSBE
CPU core count 1
Size of RAM 128 MB
Storage 32 MB, Flash
Number of 100Mbit Ethernet ports 1
Number of 100G QSFP28 ports 4
Switch chip model 98DX4310
IP rating IP66
Dimensions 330 x 200 x 70 mm
MTBF Approximately 200'000 hours at 25C
Operating system RouterOS v7, License level 5
Operating temparature -40°C to +70°C
Powering
Number of DC inputs 3 (PoE-in, DC jack, 2-pin terminal)
PoE in input Voltage 43-57 V 802.3bt
DC jack input Voltage 36-57 V
2-pin terminal input Voltage 36-57 V
Power adapter nominal voltage 48 V
Power adapter nominal current 0.95 A
Max power consumption without attachments 25 W
Max power consumption 38 W
