MikroTik XQ+85MP01D QSFP28 optical module, SM, 100m, 850nm
Product Code:
XQ+85MP01D
100,00 €
(Includes VAT 24%)
Sales price without VAT:
80,65 €
Available
MikroTik XQ+85MP01D QSFP28 optical module, SM, 100m, 850nm
Shipping cost calculation:
Quantity
Description
Characteristics
Downloads
Description
Add this QSFP module for distances up to 100 meters to your CCR2216, CRS504 or CRS518 setups and enjoy real speed and ultimate reliability. This optical module offers four independent full-duplex channels with up to 25 Gbps per channel bandwidth and an aggregate bandwidth of 100 Gbps. The module has built-in digital diagnostic functions such as optical power monitoring.
Characteristics
| Specifications | |
| Product code | XQ+85MP01D |
| Format | QSFP28 |
| Connector | 1 x 12 MTP/MPO |
| Max data rate | 100G |
| Mode | Multi mode |
| Temperature | 0°C .. +70°C |
| Wavelength | 850nm |
| Distance | 100 m |
| Optical characteristics | |
| Transmitter | |
| Output optical power (Avg.) | Min. -8.4 dBm Max. 2.4 dBm |
| Receiver | |
| Rx sensitivity (Avg.) | Max. -5.2 dBm |
| Max received pwr | Min. 3.4 dBm |
| LOS de-assert(Avg.) | Max. -13 dBm |
| LOS assert (Avg.) | Min. -30 dBm |
