TP-LINK ARCHER NX200 V2.2, 5G AX1800 Wireless Dual-Band Gigabit Router

Product Code:
ARCHER NX200
280,00 €
(Includes VAT 24%)
Sales price without VAT:
225,81 €
Available

TP-LINK ARCHER NX200 V2.2, 5G AX1800 Wireless Dual-Band Gigabit Router

Shipping cost calculation:
Quantity
Category:
Manufacturer:
Warranty:
36 Months
Description
Characteristics
Downloads
Legal Notice
Description
Boost Your 5G Speed - Take advantage of your advanced 5G network with download speeds up to 4.67 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences.
AX1800 Dual-Band Wi-Fi 6 Speed - 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz).
Plug & Play - Enjoy 5G network right after inserting a SIM card.
EasyMesh-Compatible - Co-work with EasyMesh products, to provide a more flexible and cost-effective Mesh network with a single Wi-Fi name for seamless whole-home coverage.
Gigabit WAN/LAN Port - The gigabit WAN/LAN port enables NX200 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems.

Superior 5G – A Revolutionary Experience
Take advantage of your advanced 5G network with download speeds up to 4.67 Gbps. Share your 5G network with multiple Wi-Fi devices and enjoy uninterrupted Ultra HD movies, blazingly fast file downloads, and smooth video chats and video conferences. At the same time, NX200 is backward compatible with 4G mode.**

Share 5G Speed with Reliable Wi-Fi
Thanks to cutting-edge 5G tech, NX200 boosts up to 4.67 Gbps download speeds fulfills your devices’ needs. Armed with WiFi 6 technology, NX200 is designed to deliver a huge boost in coverage, speed, and total capacity. Get on the latest mesh WiFi to enjoy the future network that loads faster and connects more.

Plug and Play, Enjoy 5G Network Everywhere
Simple, just one SIM card. Traditional broadband or cable installation is expensive and time-consuming for your vacation home, farm, or suburban warehouse. Long contract periods also create headaches for short-rentals, pop-up venues, and temporary shops to access the internet. Archer NX200 ensures a comfortable and no-block network installation. Plug in your SIM card and enjoy high-speed internet!

Flexibly Create Whole Home Mesh WiFi
If you have any dead zones at home, just add another Easymesh-Compatible router/range extender to further form your whole home multi-gigabit mesh WiFi. No more searching for a stable connection.

Available WAN Connection Backup
The gigabit WAN/LAN port enables NX200 to work as a traditional wireless router which is compatible with cable, fiber, and DSL modems. And when it's set as a wireless router, its 5G/LTE connection works as a backup to provide a sustained and reliable internet connection for you.

Easy Setup and Use
Set up the Archer NX200 in minutes thanks to its intuitive web interface and the powerful Tether app. Manage network settings, including Parental Controls and Access Control, from any Android or iOS device. Tether also provides Automatic Firmware Updates to always give your network the latest performance and security.

*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.

Characteristics
HARDWARE
Interface 2×Gigabit LAN Ports
1×Gigabit LAN/WAN Port
1×Nano SIM Card Slot
2×SMA ports for 5G/4G External Antennas
1×Power port
Buttons Wi-Fi/RESET Button, Power Button, WPS Button
Antennas 2×Internal Wi-Fi Antennas
8×Internal NR/LTE Antennas
External Power Supply 12V/2A
Dimensions 99 x 99x 190 mm
WIRELESS
Network Type 5G: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78
4G: FDD-LTE:B1/B3/B5/B7/B8/B20/B28(2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40/B41/B42/B43(2600/2300/2500/3500/3700 MH
3G: DC-HSPA+/HSPA/UMTS:B1/B5/B8(2100/850/900 MHz)
Wireless Standards IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz
Frequency 2.4 GHz and 5 GHz
Signal Rate 574 Mbps at 2.4 GHz, 1201 Mbps at 5 GHz
EIRP (CE) < 20 dBm (2.4 GHz), < 23 dBm (5 GHz)
Reception Sensitivity 5 GHz
11a 54M: -80 dBm
11ax HE20: -68 dBm 11ax HE40: -65 dBm 11ax HE80: -62 dBm
11ac VHT20: -76 dBm 11ac VHT40: -72 dBm 11ac VHT80: -68 dBm
11n HT20: -79 dBm 11n HT40: -75 dBm
2.4 GHz:
11g 54M: -78 dBm
11ax HE20: -65 dBm 11ax HE40: -62 dBm
11ac VHT20: -73 dBm 11ac VHT40: -68 dBm
11n HT20: -75 dBm 11n HT40: -72 dBm
Wireless Function Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics
Wireless Security WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3 encryptions
SOFTWARE
Operating Modes 3G/4G/5G Router, Wireless Router
WAN Type Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
DHCP Server, DHCP Client List, Address Reservation
Quality of Service Bandwidth Control
Port Forwarding ALG, Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS TP-Link, DynDns, NO-IP
VPN Server PPTP VPN, IPSec VPN, OpenVPN
Firewall Security DoS, IPv4 SPI Firewall, IPv6 Firewall, IP and MAC Address
Binding, Access Control
Protocols IPv4, IPv6
Management Access Control, Local Management, Remote Management,
reboot schedule
Guest Network 2.4 GHz guest network x 1, 5 GHz guest network x 1
OTHERS
Certification CE, RoHS
Requirements Edge, Firefox, Chrome, Safari, or other JavaScript-enabled browser
*You are recommended to use the latest version
Nano SIM Card
Environment Operating Temperature: 0℃~40℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Package Contents 5G AX1800 Wireless Dual Band Gigabit Router Archer NX200
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide



Legal Notice

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5150 – 5250MHz and 5250 – 5350MHz, provides for a maximum transmit power of 200 mW e.i.r.p. and in the frequency band 5470 – 5725MHz, provides for a maximum transmit power of 1 W e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.
