Ubiquiti ACB-ISP airCube ISP, airMAX Home Wi-Fi Access Point
ΠΡΟΣΟΧΗ!!! Στην συσκευασία δεν συμπεριλαμβάνεται το τροφοδοτικό!!!
Ubiquiti Networks introduces the airCube™, a cost-effective wireless access point for use in your customer deployments.
Wireless Performance
Two models are available:
• airCube AC Dual-band, 802.11ac, 2x2 MIMO technology for maximum wireless performance:
- 2.4 GHz radio band Speeds of up to 300 Mbps
- 5 GHz radio band Speeds of up to 866.7 Mbps
• airCube ISP 802.11n, 2x2 MIMO Wi-Fi for speeds of up to 300 Mbps in the 2.4 GHz radio band
Versatile Power Options
Both models offer convenient PoE passthrough to power a 24V airMAX CPE device, so you can use a single PoE adapter to power both devices.
To provide sufficient power for PoE passthrough:
• The airCube ISP requires 24V, 1A PoE input or a 2A Micro USB adapter (not included).
Intuitive Software
Management options feature a graphical user interface designed for streamlined setup and control.
Available options include:
• UMobile App Supports quick setup and status information.
• Web UI Enables a standalone utility for basic configuration.
• UNMS Provides advanced remote control of Ubiquiti® devices.
airCube-ISP
• (4) 10/100 Fast Ethernet Ports
• 24V PoE Passthrough for airMAX CPE
• 802.11n, 2x2 MIMO Technology
• Up to 300 Mbps in the 2.4 GHz Radio Band
• Powered by 24V Passive PoE or 2A Micro USB Adapter (Not Included)
| Specifications | |
| Dimensions | 87.80 x 89.50 x 89.25 mm |
| Weight | 215 g |
| Power Supply | 5V |
| Power Method | PoE 24V In on LAN Port 1 or 2A Micro USB Adapter (Not Included) |
| Supported Power Voltage | 4.95-5.05V |
| Max. Power Consumption | 5W |
| PoE Out | Controllable 24V PoE Out (+4, 5; -7, 8) on WAN Port |
| Management Interface | Wi-Fi / Ethernet |
| Networking Interface | (4) 10/100 Fast Ethernet Ports |
| LED | Status |
| Max. TX Power | 22 dBm |
| Antenna Gain | 2.4 GHz: 4 dBi |
| Max. Speeds | 2.4 GHz: 300 Mbps |
| Enclosure Characteristics | Black Plastic |
| ESD/EMP Protection | ±24 kV RJ-45 Interface |
| Operating Temperature | -10 to 50° C (-14 to 122° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 2400 – 2483,5 MHz, προβλέπει μέγιστη ισχύ εκπομπής τα 100 mW e.i.r.p.
Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
