DAHUA PFM300 Power Supply 12V 2A
Κωδικός προϊόντος:
PFM300
Άμεσα διαθέσιμο
DAHUA PFM300 Power Supply 12V 2A
Υπολογισμός κόστους μεταφορικών:
Καλέστε για τιμή
Περιγραφή
Χαρακτηριστικά
Λήψεις
Περιγραφή
• Easy installation and wall mount, structural water-proof;
• Support -30 ℃ ~+70 ℃ wide-range temperature operation, and the full load efficiency of the power supply can be up to 100% at these temperatures;
• With junction function for camera wiring or can place video balun with HDCVI/AHD/TVI/CVBS cameras;
• Made of PC environmental protection material, which meets “V0” fire protection;
• Accurate over current, voltage load protection.
Χαρακτηριστικά
| Technical Specifications | |
| Model | DH-PFM300 |
| Electrical Specification | |
| Rated input | AC180~264V, 50/60Hz, 0.6A |
| Efficiency | 82% |
| no-load power consumption | <0.5W |
| Output voltage | DC12V (±5%) |
| Output current | 2A (±2%) |
| Protection/Environmental | |
| Protection | Accurate over current, voltage load protection “V0” fire protection |
| Working temperature | -30℃~+70℃ |
| Working humidity | <90% RH |
| Physical Properties | |
| Weight | 160g |
| Dimension(LxWxH) | 88mmx37mmx138mm |
| Installation | Wall mount |
| Color | Grey |
| Input | Palisade terminal |
| Output | DC output wire 60mm (interface: φ5.5×φ2.1) |
| Safety Standards | |
| Certification | CE |
Λήψεις
