Ubiquiti UA-G3-FLEX-W UniFi Access Reader G3 Flex, White
Ubiquiti UA-G3-FLEX-W UniFi Access Reader G3 Flex, White
Ubiquiti Reader Flex is the third generation of access readers, supporting authorization via NFC card, Apple Touch Pass *, the UniFi Identity mobile app, or a numeric code. Thanks to the built-in speaker, it is possible to configure entry and exit greeting messages. The mechanical design of the keypad ensures functionality even with moisture or most gloves. Its IP55 certification guarantees suitability for outdoor use.
The reader features (1) 10/100Mbps Ethernet port with POE support. The minimum required version of the application is UniFi Access 3.0.15.
* Users will receive 10 free Touch Passes in the first year to get started. Additional passes are $5 per user per year.
Package Contents:
Reader
(2) Drilling templates
(2) Mounting frames
Cover frame
Rubber cover for the RJ45 connector
Installation accessories
| Specifications | |
| Overview | |
| Dimensions | 84 x 84 x 40.8 mm |
| NFC Card & Keyfob Access | Yes |
| PIN Access | Yes |
| Apple/Google Wallet | Yes |
| Mobile Unlock | Yes |
| Handwave Request to Exit | Yes |
| NDAA Compliant | Yes |
| UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Weatherproofing | IP55 |
| Mechanical | |
| Weight | 165 g |
| Enclosure material | Polycarbonate, glass |
| Mount material | Aluminum alloy |
| Mounting | Wall (Included) Gang-box, junction box (Optional) |
| Hardware | |
| Indoor and Outdoor Use | Yes |
| Ambient Operating Temperature | -30 to 60° C |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (1) 10/100 MbE RJ45 port |
| Connectivity | BLE 4.1 NFC |
| Power Method | PoE UL 294 Power-limited Class 2 PSU UL 60950-1/62368-1 LPS/PS2 PSU |
| Max. Power Consumption | 5W |
| Supported Voltage Range | 44-57V DC |
| ESD/EMP Protection | Air: ±15kV, contact: ±8kV |
|
Sensors
|
(12) Capacitive buttons |
| Speaker | Yes |
| LEDs | R/G/B/W |
| Button | (1) Factory-reset |
| NFC Frequency | 13.56 MHz |
| NFC Read Range | < 30 mm (1.18'') |
| NFC Read Range | ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340) MIFARE Classic / MIFARE DESFIRE Sony FeliCa™ (ID only) NFC Forum tags T1T, T2T, T3T, T4T and T5T ECP 2.0 |
| PoE Cabling Requirements | Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site. The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable. |
| UL 294 Statement | Compliance with IEEE 802.3 specifications was not verified as part of UL 294. The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits. |
| CAN/ULC-60839-11-1 Grade | Grade assignment: I |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Document number, and issue date and/or revision level | UA-G3-Flex V01 |
| Software | |
| Management application | Access |
