TP-LINK TAPO C545D V1 Outdoor Dual Lens Pan/Tilt Security Camera
TP-LINK TAPO C545D V1 Outdoor Dual Lens Pan/Tilt Security Camera
| • 2K 3MP Dual Lens - Capture the full picture with dual 2K high definition optics, monitoring two separate areas at the same time with just one device. Engineered to minimize blind spots for optimal coverage. • Wide-Angle & Telephoto Lens - With 165° FOV wide-angle lens and 6mm telephoto lens, it ensures all-around awareness and down-to-the-detail protection of your home. • Synchronized Smart Tracking - When the fixed lens detects events, the pan/tilt lens will automatically pivot to focus on and track the moving object. • One-Tap Smart Focus - Select an area in the wide-angle view, and the pan/tilt camera will focus on it instantly. • IP66 Weather Resistance - Delivers reliable surveillance through rain, snow, dust, and scorching heat. Monitor your property with confidence, no matter the weather. • Ethernet Support - Ideal for areas with weak Wi-Fi, an Ethernet connection guarantees smooth live streaming and faster data transmission. • Free AI Detection & Notification - Get instant push notifications when motion, person, pets and vehicles are detected, there is no additional fee to use it. • Works with Alexa, Google Assistant & Samsung SmartThings - Fully compatible with Amazon Alexa, Google Assistant and Samsung SmartThings. • Smart Night Vision -Choose from vibrant full-color with spotlights, discreet black-and-white infrared, or an automatic Smart Mode based on Al light detection for optimal clarity in any nighttime scenario. • Secure Local or Cloud Storage - Save footage continuously on up to a 512 GB microSD card (not included) or subscribe to Tapo Care for cloud storage which saves 30-day video. • 2-Way Audio - Engage in seamless, real-time conversations with our two-way audio feature, designed for minimal latency and exceptional sound clarity. |
Pan, Tilt, and Capture It All
The top wide-angle lens is fixed in place but supports manual Pan (270°) and Tilt (-30° to -10°) adjustment for the best viewing angle. The bottom telephoto lens features automatic pan and tilt to follow motion or shift focus between different areas as needed.
Synchronised Smart Tracking
The two cameras dynamically work together to seamlessly follow movement–when the fixed lens detects events like motion, people, and pets, the pan/tilt lens will automatically pivot to focus on and track the moving object.
Magnify Details with Telephoto Lens
The 6mm telephoto lens delivers 3× clarity compared to standard lens and supports up to 10.8× digital zoom, ensuring every detail is clearly visible when you zoom in.
Panoramic Coverage of Two Areas, Simultaneously
Monitor two separate areas at the same time with just one powerful camera. Reduce blind spots and get a more thorough, comprehensive overview of your home.
Instant Detail with One-Tap Smart Focus
One tap for instant clarity: select an area in the wide-angle view, and the pan/tilt camera will focus on it instantly.△
Smarter, More Accurate Notifications Powered by AI
Stay informed with smart AI detection that recognises and notifies you of people, pets, and vehicles – all without any subscription fees. Tailor your alerts by selecting which types of detection will trigger notifications.
Smart AI accurately identifies people, pets, and vehicles, reducing false alerts and unnecessary notifications.
Smart & Versatile Night Vision Modes
Choose from vibrant full-colour with spotlights, discreet black-and-white infrared, or an automatic Smart Mode based on AI light detection for optimal clarity in any nighttime scenario.
Reliable Connectivity with Ethernet Support
Ensure a more stable and consistent connection for your camera with Ethernet support. Ideal for areas with weak Wi-Fi, an Ethernet connection guarantees smooth live streaming and faster data transmission.
Engineered for Weather Resilience
Delivers reliable surveillance through rain, snow, dust, and scorching heat. Monitor your property with confidence, no matter the weather.
• Operates in environments reaching 140°F (60°C)
• IP66 rating withstands water and dust
• Temperature resistance down to -22°F (-30°C)
Adaptable Installation Options
Tapo C545D can be securely mounted on a wall, affixed to the celling, or even held by a rod* - designed to withstand the elements and deliver dependable monitoring across diverse outdoor settings
†MicroSD card needs to be purchased separately. Actual storage capacity depends on the size of the microSD card used.
‡Subscribe for cloud storage at https://www.tapo.com/tapocare/
§Tapo H500 & H200 need to be purchased separately. Actual support may vary. Please refer to the official H500 & H200 supported device list for accuracy.
△Manual zoom-in is required to enlarge the PT lens image during live view. Actual operation may vary. Please follow the instructions in the Tapo app.
*The pole-mounting loop is not included and should be purchased separately.
| SPECIFICATIONS | |
| Camera | |
| Image Sensor | 1/2.8“ Progressive Scan CMOS Sensor |
| Lens | Focal Length: 6 mm ± 5%, 2.53 mm±5% Aperture: F1.6 ± 10%, F1.6 ± 10% Field of View: 66.5° (Diagonal), 57.3° (Horizontal), 31.7° (Vertical); 165.1° (Diagonal), 137.6° (Horizontal), 73.0° (Vertical) |
| Night Vision | 850 nm IR LED (99 ft / 29.9 m), Color Night Vision |
| Day/Night Switch | IR-Cut Filter with Auto-Switching |
| Interface & Button | 1× RJ45 (10M/100M) Ethernet Port 1× RESET Button 1× microSD Card Slot (Up to 512 GB) |
| Video & Audio | |
| Maximum Resolution | 2K 3MP (2304 x 1296 px) + 2K 3MP (2304 x 1296 px) |
| Frame Rate | 15 fps |
| Video Compression | H.264 |
| Live View | Yes |
| Image Enhancement | 3DNR WDR |
| Audio Input & Output | Built-in microphone and speaker |
| Audio Communication | Two-Way Audio with Noise Cancellation |
| Siren Volume | 99 dB (Level measured at 4-inch/10-cm distance) |
| Storage | |
| Local Storage | microSD Card Slot on Camera (Up to 512 GB) |
| Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
| Detection & Notification | |
| AI Detection | Motion Detection Person Detection Pet Detection Vehicle Detection Line-Crossing Detection Camera Tampering |
| Activity Zones | Yes *Only works with Motion/Person/Pet/Vehicle Detection |
| Output Notification | System Notification System Notification with Snapshot (Tapo Care Services) |
| Network | |
| Network Connectivity | Connect via Wi-Fi or Ethernet |
| Wireless Connectivity | IEEE 802.11 b/g/n/ax, 2.4 GHz |
| Transmission Rate | 11b: 11 Mbps 11g: 54 Mbps 11n: 72.2 Mbps 11ax: 143.4 Mbps |
| Protocol | TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP |
| Ethernet Port | Yes |
| RTSP | Yes |
| ONVIF | Yes |
| Security | |
| Security | On-Device Machine Learning 128-bit AES Encryption with SSL/TLS WPA/WPA2-PSK/WPA3 |
| Power | |
| Power Source | 12 V DC Power Adapter |
| Input Voltage | 100-240 V, 50/60 Hz |
| Output Voltage | 12 V, 1 A (DC Power) |
| DC Power Connector Size | Inside Ø: 2.1 mm Outside Ø: 5.5 mm |
| Power Cord Length | 3 m |
| Typical Power Consumption | 5.3 W |
| Maximum Power Consumption | 11.2 W |
| General | |
| Smart Integration | Google Assistant, Amazon Alexa, Samsung SmartThings |
| Weather Resistance | IP66 |
| Mounting Options | Wall-Mounted Eave-Mounted Pole-Mounted |
| Operating Temperature | -30 ºC ~ 60 ºC |
| Storage Temperature | -40℃ ~ 60℃ |
| Operating Humidity | 10%~90% RH, Non-condensing |
| Storage Humidity | 0%~90% RH, Non-condensing |
| Dimensions | 114.57 × 159.55 × 152.1 mm |
| Weight | 491 g |
| Package Contents | Tapo C545D Camera ×1 Mounting Bracket ×1 Mounting Template Sticker ×1 Mounting Screws ×4 Mounting Anchors ×4 Waterproof Seal ×1 Waterproof Cable Attachments ×1 Power Adapter ×1 Quick Start Guide |
