TP-LINK FUSION 2.5G V2, Omada Fusion 2.5G Gateway
TP-LINK FUSION 2.5G V2, Omada Fusion 2.5G Gateway
|
• License‑Free Cloud Management for Easy and Secure Remote Access |
Fusion Gateway at the Center of the Omada Networking Ecosystem
Gateway and controller integrated into a single device, delivering a unified solution that combines networking and centralized management at the core of the Omada networking ecosystem—improving the installation and management experience.
Simplified Setup for Faster Deployment, Boosting Efficiency
Easily set up the Fusion 2.5G via Bluetooth using the Omada App. Automatically discover and batch adopt all other Omada networking devices at once, saving time and simplifying IT deployment.
Quick Troubleshooting via Touchscreen, Reducing On-Site Work
With an innovative 2.51-inch touchscreen, enjoy quick troubleshooting — all at your fingertips. Reduce on‑site work and save time with direct, on‑device monitoring.
Secure Remote Network Access, One Click Away
With Omada LightLink VPN, you can securely access your network from anywhere with one click. Powered by Smart Split Tunneling, only essential traffic goes through the VPN, reducing unnecessary VPN load and preserving a smooth user experience.
*Actual throughput may vary depending on traffic conditions, enabled features, and network environment.
**Magnetic‑mount plate and rack‑mount kit are sold separately.
§Controller and management features may vary depending on connected Omada devices, software versions, and deployment modes. The stated management capacity is based on laboratory testing. Actual management capacity and performance may vary depending on deployment and network conditions.
† Performance data is based on IPsec VPN.
| Overview | |
| Built-In Omada OS Applications | Network Application |
| Managed Omada Devices | Recommended for up to 30 devices |
| Client Capacity | Recommended for up to 300 connected clients |
| Interface | • 1× 2.5G RJ45 WAN port • 4× 2.5G RJ45 LAN/WAN ports • Up to 4 simultaneous WAN ports |
| Mounting | • Desktop • Wall-mount (magnetic-mount plate sold separately)** • Rack-mount (rackmount kit sold separately)** |
| Dimensions | 160 × 130 × 31.5 mm |
| Hardware | |
| Standards and Protocols | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1q, IEEE 802.1p, IEEE 802.1ab, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, SNMP, LLDP |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) 2.5GBASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| CPU | Quad-Core |
| Memory | 2 GB DDR4 |
| Touchscreen | 2.51-inch color LCM touchscreen |
| Button | Reset Button |
| Enclosure | Polycarbonate |
| LED | Ethernet |
| Fan | Fanless |
| Antenna | 1× BLE Antenna |
| Net Weigh | 510 g |
| Power Supply | USB Type C (5V DC / 3A) (Adapter included) |
| Max Power Consumption | 8.18 W, with power adapter |
| Surge Protection | 4 kV surge protection |
| ESD Protection | ±8 kV (Air) ±4 kV (Contact) |
| Onboarding | Bluetooth or Ethernet |
| MTBF | 613,523 h @ 25 °C |
| Performance | |
| Concurrent Sessions | 150,000 |
| New Sessions/Second | 7,800 |
| Static IP NAT Throughput (Upload/ Download) |
2,362 Mbps / 2,361 Mbps |
| DHCP NAT Throughput (Upload/ Download) |
2,363 Mbps / 2,359 Mbps |
| PPPoE NAT Throughput (Upload/ Download) |
2,355 Mbps / 2,357 Mbps |
| L2TP NAT Throughput (Upload/ Download) |
1,727 Mbps / 1,235 Mbps |
| PPTP NAT Throughput (Upload/ Download) |
1,843 Mbps / 1,399 Mbps |
| 66 Byte Packet Forwarding Rate (Upload/Download) |
3,472,452 pps / 3,472,359 pps |
| 1,518 Byte Packet Forwarding Rate (Upload/Download) |
202,671 pps / 202,668 pps |
| Omada LightLink VPN Throughput | 527 Mbps |
| IPSec VPN Throughput | ESP-SHA1-AES256: 1,023 Mbps ESP-SHA256-AES256: 1,073 Mbps ESP-SHA384-AES256: 972 Mbps ESP-SHA512-AES256: 1,087 Mbps |
| OpenVPN Throughput | 223 Mbps |
| L2TP V PN Throughput |
892 Mbps |
| PPTP VPN Throughput |
193 Mbps |
| SSL VPN Throughput | 250 Mbps |
| WireGuard VPN Throughput | 605 Mbps |
| IPS Throughput (Upload/Download) | 2,183 Mbps / 2,152 Mbps |
| DPI Throughput (Upload/Download) | 2,206 Mbps / 2,219 Mbps |
| Networking | |
| WAN Connection | Static IP / Dynamic IP / PPPoE / PPTP / L2TP / MAP-E / DS-Lite |
| Multi-WAN Failover & Load Balancing | Yes |
| DHCP | DHCP Server DHCP Options Customization DHCP Address Reservation Multi-IP Interfaces Multi-Net DHCP WAN DHCP Option 60 |
| VLAN | 802.1Q VLAN |
| MAC Clone | Yes (Customizable WAN MAC Address) |
| Bridge VLAN | Yes |
| Virtual WAN | WAN Connection Type: Static IP, Dynamic IP, PPPoE Max Virtual WAN Entries: 3 |
| Bandwidth Control | Yes |
| QoS | Yes |
| Routing | Static Routing Policy Routing |
| NAT | Virtual Server NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG UPnP One-to-One NAT Disable NAT |
| Dynamic DNS | Dyndns, No-IP, Peanuthull, Comexe, TP-Link DDNS, DDNS Customization |
| IPv6 | Static IP / SLAAC / DHCPv6 / PPPoE / 6to4 Tunnel / Pass-Through / Non-Address Mode |
| Bonjour / mDNS | Yes |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Session Limit | IP-Based Session Limit |
| Security | |
| IDS/IPS | Signature-Based IPS/IDS Threat Detection |
| DPI | Deep Packet Inspection (DPI) Application Filter Rules |
| ACL | Source/Destination IP-Based ACL Application-Based ACL Stateful ACL IPv4/IPv6 ACL Nation-Based ACL FQDN |
| Content Filtering | URL Category, Ad Block, Allow List, Block List |
| Safe Search | Yes |
| Secure DNS | DNSSEC, DoH, DoT, DNS Redirection |
| Firewall | Stateful Firewall Attack Defense |
| ARP Inspection | Yes |
| MAC Filtering | Yes |
| IP-MAC Binding | Yes |
| VPN & SD-WAN | |
| Site-to-Site VPN | WireGuard VPN / IPsec VPN |
| VPN Server | WireGuard VPN / OpenVPN / IPsec VPN / SSL VPN / L2TP VPN / PPTP VPN |
| VPN Client | WireGuard VPN / OpenVPN / L2TP VPN / PPTP VPN |
| SD-WAN | Full Mesh Mode |
| Omada LightLink VPN | Invite by Link Invite by Email Max LightLink Clients: 253 |
| IPSec VPN | Max IPSec VPN Tunnels: 20 LAN-to-LAN, Client-to-LAN Main and Aggressive Negotiation Modes DES, 3DES, AES128, AES192, and AES256 Encryption Algorithms IPSec Failover IKE v1/v2 MD5, SHA1, SHA256, SHA384, and SHA512 Authentication Algorithms NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) |
| PPTP VPN | PPTP VPN Server Max PPTP VPN Clients: 10 Max PPTP VPN Tunnels: 16 PPTP with MPPE Encryption |
| L2TP VPN | L2TP VPN Server Max L2TP VPN Clients: 10 Max L2TP VPN Tunnels: 16 L2TP over IPSec |
| OpenVPN | OpenVPN Server Max OpenVPN Clients: 10 Max OpenVPN Tunnels: 110 "Certificate + Account" Mode Full Mode Split Mode |
| SSL VPN | Max SSL VPN Tunnels: 80 |
| Built-in Omada Controller | |
| Cloud Access | Yes |
| Local Management | Yes |
| Omada App | Yes |
| Multi-Site Management | Via the Omada Cloud Management Platform |
| Restore & Backup | Yes |
| Automatic Device Discovery | Yes |
| Network Topology | Yes |
| Dashboard | Yes |
| Device List / Client List | Yes |
| Logs / Alerts / Events | Yes |
| Batch Firmware Upgrade | Yes |
| Health Monitoring | Yes |
| Internet Activity | Yes |
| Captive Portal | Yes |
| RADIUS / LDAP Authentication | Yes |
| 802.1X Authentication | Yes |
| OUI-Based VLAN | Yes |
| Diagnostics Tools | Ping Test, Packet Capture, Terminal, Cable Test, Interference Detection, Remote Access, IntelliRecover, Port Mirroring |
| SNMP | v1/v2c/v3 |
| Management & Maintenance | |
| Management | Cloud, local, and Omada App management |
| Maintenance | Web Management Interface Remote Management Export & Import Configuration SNMP v1/v2c/v3 Diagnostics (Ping & Traceroute) NTP Synchronization Port Mirroring Syslog Support |
| Environment & Certifications | |
| Environment | Operating Temperature: -10 °C to 40 °C Storage Temperature: -30 °C to 70 °C Operating Humidity: 10% to 90% non-condensing Storage Humidity: 5% to 90% non-condensing |
| Certifications | CE, FCC, RoHS |
