| • Up to 15 m detection distance range • Night vision • Advanced Pet immunity • Anti-masking system • Up to 3 years of operation from batteries • Communication with the hub at distance of up to 1,700m |
Motion detected. Alarm raised. Evidence captured
With MotionCam Outdoor, users know about the actual situation even before the burglars understand that they’re busted. An animated series of photos made by a wide dynamic range camera follows the instant motion alarm for an accurate situation appraisal. Photos are transmitted via an encrypted proprietary radio protocol and displayed in the Ajax apps or third-party monitoring software.
False alarm prevention
MotionCam Outdoor features a system of two independent PIR sensors that collect enough data to analyse the threat's reality with the LISA two-step software algorithm. LISA compares the frequency components of sensors signals — it is the know-how of the Ajax Systems that guarantee the detector accuracy
Weatherproof design
MotionCam Outdoor is ready to operate in a wide range of climate zones. The detector is protected from dust and splashes and features a temperature compensation technology, making it effective in any weather conditions. The bundled hood protects masking sensors from rain and snow.
Hassle free installation
To add a detector to the system, an installer scans the QR code with the Ajax app and assigns a name and a room. Configuring is done in the app in real-time using detection zone and signal strength tests. The detector can be disabled or its system parameters can be reconfigured remotely
Antisabotage protection
The anti-masking system calibrates automatically when mounting the device onto SmartBracket. Then, if an obstacle appears in the field of view of anti-masking sensors or if they are painted, the detector notifies users and a security company. A tamper is immediately activated when the detector is dismounted from the bracket. The system needs less than a minute to identify communication loss with the detector.
Guaranteed alarm delivery
We ve developed the Jeweller radio protocol to ensure the uninterrupted operation of all system devices. The radio protocol uses time frames to synchronize communication of connected devices, authentication to eliminate forgery, and encryption to protect against hacking
Secure photo transmission
We ve developed Wings an encrypted two way radio protocol to securely deliver photos at a significant distance. It allows receiving visual alarm verification in a matter of seconds. Working in parallel with Jeweller, Wings does not interfere with it, providing stable data communication with a compatible hub at a distance of up to 1,700 meters.
| Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 863 – 870 MHz, προβλέπει μέγιστη ισχύ εκπομπής όπως περιγράφεται στην απαίτηση διεπαφής ραδιοεξοπλισμού 105. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T. Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017 Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς και εξωτερικούς χώρους. |
| Εγγυήσεις - Επιστροφές: | |
| Επιστροφή Χρημάτων: | Επισκευή - Αντικατάσταση: |
| 20 ημέρες | 24 μήνες |
| Technical Specifications | |
| Compatibility | |
| Compatible hub models | Hub 2 (2G) / Hub 2 (4G) / Hub 2 Plus / Hub Hybrid (2G) / Hub Hybrid (4G) |
| Compatible range extenders | ReX 2 |
| Communication | |
|
Communication technology |
• Jeweller • Wings |
| Maximum effective radiated power (ERP) (Jeweller) |
up to 20 mW |
| Radio signal range (Jeweller / Wings) |
up to 1,700 m Between detector and hub or range extender in an open space. |
| Encrypted communication (Jeweller) |
All stored and transmitted data are protected by block encryption featuring a dynamic key. |
| Radio frequency hopping (Jeweller / Wings) |
To prevent radio interference and jamming. |
| Detection | |
| Sensitive element | 2x PIR sensor |
| Photo by Alarm | A built-in camera is activated if the detector is armed and motion is detected. |
| Motion detection distance |
up to 3–15 m
When installed at a height of 0.8–1.3 m. Adjusted with a scrollbar on the device enclosure.
|
| Motion detection angles | horizontal — 90° |
| Camera angles | horizontal — 101° vertical — 50° |
| Motion detection speed |
from 0.3 to 2.0 m/s
The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility.
|
| Sensitivity |
3 levels
Adjusted by PRO or user with admin rights in the Ajax app. |
| Pet immunity | weight: not relevant height: up to 80 cm |
| False alarm prevention |
LISA
SmartDetect
Software algorithms.
|
| Temperature compensation | Effective motion detection at temperatures from −25°C to +60°C. |
| Anti-sabotage protection | • Tampering alarm • Anti-masking system • Protection against spoofing • Communication loss detection |
| Power supply | 4 × CR123A battery Type C |
| Battery life |
up to 3 years
with Delay when entering feature disabled
up to 2.5 years
with Delay when entering feature enabled
|
| Enclosure | |
| Dimensions | 206 × 108 × 93 mm |
| Weight | 470 g |
| Operating temperature range | from −25°C to +60°C |
| Operating humidity | up to 95% |
| Protection class | IP55 |
| Package contents |
MotionCam Outdoor Jeweller
Hood visor
SmartBracket mounting panel
Installation kit
4 × CR123A battery (Pre-installed)
Quick Start Guide
|
