TP-LINK POE2412G, V2.2 Gigabit 24VDC Passive PoE Adapter
Product Code:
POE2412G
15,00 €
(Includes VAT 24%)
Sales price without VAT:
12,10 €
Available
TP-LINK POE2412G, V2.2 Gigabit 24VDC Passive PoE Adapter
Shipping cost calculation:
Quantity
Description
Characteristics
Downloads
Description
| • 24V passive PoE supported • Auto-determine the necessary power requirements • Convenient wall-mounting design • Gigabit speed support • Plug-and-Play, requires no configuration |
The POE2412G is a 24V/12W passive PoE adapter that provides simultaneous power and data transmission to compatible devices through a single Ethernet cable. This wall-mountable device comes with convenient mounting brackets for easy installation and is compatible with access points and Customer Premises Equipment, such as EAP245 and CPE610.
Characteristics
| Specifications | |
| Interface | 2×10/100/1000 Mbps RJ45 Port AUTO Negotiation/AUTO MDI/MDIX 1 AC POWER INPUT Port |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 1000 STP (Max 100 m) 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 1000 STP (Max 100 m) 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Output Voltage | 24VDC (Max. 12W) |
| LED Indicator | PWR |
| Dimensions | 85.8 mm×43.9 mm×35 mm |
| Certification | FCC, CE, RoHS |
| Package Contents | 24V12W Passive PoEAdapter POE2412G Power Cord Wall Mounting Kits |
| Environment | Operating Temperature: 0°C~45°C Storage Temperature: -40°C~70°C Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
