TP-LINK EAP215-Bridge KIT Omada Wireless Bridge 5 GHz 867 Mbps Long-Range Indoor/Outdoor Access Point
Product Code:
EAP215-Bridge KIT
179,00 €
(Includes VAT 24%)
Sales price without VAT:
144,35 €
Available
TP-LINK EAP215-Bridge KIT Omada Wireless Bridge 5 GHz 867 Mbps Long-Range Indoor/Outdoor Access Point
Shipping cost calculation:
Quantity
Category:
Manufacturer:
Description
Characteristics
Downloads
Description
| • 802.11ac for up to 867Mbps on 5GHz wireless data rate*1 • Ideal for long-range wireless transmission up to 5 km.*2 • Auto-pairing and agile LEDs for efficient deployment • 3× Gigabit Ethernet ports for more high-speed IP camera connections. • Supports Omada SDN for remote and centralized management. • IP65 weatherproof enclosure and 6kV lightning protection ensure all-weather suitability.*3 • Supports Passive PoE for flexible deployment (adapter included). |
Omada Solution
Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface.
| Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5470 – 5725MHz, provides for a maximum transmit power of 1 W e.i.r.p. At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C. This product is CE marked, P.D. 98/2017 This product is intended for outdoor use. |
| Warranties - Returns: | |
| Money Return: | Repair - Replacement: |
| 20 days | 36 months |
Characteristics
| Main Design | |
| LAN Interfaces | 3x Gigabit Ethernet Port |
| Wi-Fi Standards | IEEE 802.11a/n/ac |
| Maximum Data Rate | 867 Mbps (5 GHz) |
| Wireless Client Capacity | 8 |
| Antennas | Internal 2×2 Dual-polarized directional MIMO antenna 5 GHz: 11.0 dBi |
| Transmit Power | CE: <23dBm (5 GHz, band 1/2, EIRP) <30dBm (5 GHz, band 3, EIRP) FCC: <22dBm (5GHz band 1/4) |
| Reception Sensitivity | 5GHz: 11ac VHT20 MCS0:-94dBm 11ac VHT20 MCS8:-71dBm 11ac VHT40 MCS0:-90.5dBm 11ac VHT40 MCS9:-66.5dBm 11ac VHT80 MCS0:-87.5dBm 11ac VHT80 MCS8:-63dBm |
| Centralized Management | |
| Omada Software Controller | Yes |
| Omada Hardware Controller | Yes |
| Omada APP | Yes |
| Security | |
| Captive Portal Authentication | Yes |
| Access Control | Yes |
| Maximum number of MAC Filter | 4000 |
| VLAN | Yes |
| Rogue AP Detection | Yes |
| Wireless Encryption | Yes |
| Wireless Function | |
| Multiple SSIDs | 8 |
| Channel | 5G: 36,40,44,48,52,56,60,64,100,104,108,112,116, 120,124,128,132,136,140 |
| Enable/Disable Wireless Radio | Yes |
| Enable/Disable SSID Broadcast | Yes |
| Guest Network | Yes |
| QoS (WMM) | Yes |
| Mesh | Yes |
| Beamforming | Yes |
| MU-MIMO | 5G 2x2 MU-MIMO DL |
| Rate Limit | Yes |
| Load Balance | Yes |
| Airtime Fairness | Yes |
| RADIUS Accounting | Yes |
| MAC Authentication | Yes |
| Reboot Schedule | Yes |
| Wireless Schedule | Yes |
| Wireless Statistics | Yes |
| Static IP/Dynamic IP | Yes |
| Support Data Rates | |
| 802.11ac | 6.5 Mbps to 867 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80) |
| 802.11n | 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40) |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Management | |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| Web-based Management | Yes |
| SNMP | Yes |
| SSH | Yes |
| Restore & Backup | Yes |
| Firmware update via Web | Yes |
| NTP | Yes |
| System Log | Yes |
| Physical & Environment | |
| Power Supply | 12V DC / 24V Passive PoE |
| Maximum Power Consumption | 11.5W |
| Reset | Yes |
| Mounting | Pole mounting (Accessories included) |
| Others | |
| Certifications | CE, FCC, RoHS |
| Dimensions (W x D x H) | 224 × 79 × 60 mm |
| Net Weight | 330.9g |
| Enclosure Material / Rack Material | Enclosure: ASA-HB Pole Mounting Straps: Nylon 66 |
| Lightning Protection | Air discharge: ±8kV Contact discharge: ±4kV Common mode 10/700: ±6kV |
| Environment | Operating Temperature: -40 °C – 70 °C Storage Temperature: -40 °C – 70 °C Operating Humidity:10% – 90% non-condensing Storage Humidity: 5% – 90% non-condensing |
