Ubiquiti USP-RPS UniFi Redundant Power System
The UniFi® SmartPower Redundant Power System, model USP-RPS, is a proprietary redundant power system designed to protect up to six UniFi SmartPower supported devices from sudden power supply module failure. The USP-RPS continually monitors all attached devices. In the event of an internal AC/DC power supply failure, failover is automatic so your network continues to operate with no interruption in service. With a 950W DC power budget, the USP-RPS can protect a variety of high-power devices, including UniFi PoE switches. An integrated 1.3" color touchscreen LCM displays system information for convenient monitoring.
Features
• (6) USP DC output ports
• (1) Ethernet port
• 1U Rackmountable (kit included)
• 1.3" Touchscreen display with status information
• Managed by UniFi Network Controller version: 5.12.11 or later
| Specifications | |
| Dimensions | 442.4 x 325.60 x 43.7 mm |
| Weight With Brackets Without Brackets |
5.59 kg 5.50 kg |
| Interfaces Networking Management Power Output |
(1) 10/100/1000 Mbps RJ45 Port Ethernet In-Band (6) RPS DC Ports |
| Power Method | (1) Universal AC Input, 100 to 240 VAC |
| Power Supply | Internal 350W AC/DC Internal 645W AC/DC |
| Supported Voltage Range | 100 to 240VAC |
| Max Power Consumption | 995W |
| Display | 1.3" Color Touch Panel |
| LEDs System RJ45 Data Ports USP RPS |
Status Link/Activity Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Operating Temperature | -5 to 45° C |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
| RPS | |
| Total Output Power 52 VDC 11.5 VDC |
11.54A (600W) 30.44A (350W) |
| Max Output Power per RPS Port 52 VDC 11.5 VDC |
11.54A (600W) 30.44A (350W) |
