MikroTik H53UiG-5HaxQ2HaxQ, Chateau Pro Ax
Designed with professional users in mind, the Chateau PRO ax Wi-Fi 6 home access point is engineered to squeeze out maximum performance, handling more traffic than ever before. With its unstoppable quad-core ARM CPU running at 2.2 GHz and our latest cutting-edge wireless chip, Chateau PRO ax leverages 4 spatial streams to achieve double the data rate of the usual dual-chain devices, ensuring that your network is always fast, reliable, and ready to support even the most demanding tasks. Remember – you will need a device that supports 4 spatial streams on the other side of the connection to fully utilize the Chateau PRO ax.
With 5x Gigabit Ethernet ports and a USB 3.0 port, you can transform this Chateau into a home media server by plugging in an additional SSD storage. Or you could use the USB to add an LTE modem for backup!
Advanced container setups, bonding, or high-speed 4x4 MIMO wireless setups – that’s where the Chateau PRO ax can really shine! Also, its increased number of radio transceivers provides significantly improved wireless coverage and beamforming performance.
| Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p. At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C. This product is CE marked, P.D. 98/2017 This product is intended for indoor use. |
|
| Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5470 – 5725MHz, provides for a maximum transmit power of 1 W e.i.r.p. At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C. This product is CE marked, P.D. 98/2017 This product is intended for indoor use. |
| Warranties - Returns: | |
| Money Return: | Repair - Replacement: |
| 20 days | 12 months |
| Specifications | |
| CPU | Quad-Core IPQ-8072A 2208 MHz |
| CPU architecture | ARM 64bit |
| Size of RAM | 1 GB |
| Storage | 128 MB, NAND |
| RAM type | DDR3 |
| Number of 1G Ethernet ports | 5 |
| USB | 1 (3.0 type A) |
| Switch chip model | IPQ-8072 |
| Wireless interface model | QCN-5024 (2.4 GHz), QCN-5054 (5 GHz) |
| Wireless | 2.4 GHz 802.11b/g/n/ax, 5 GHz 802.11a/n/ac/ax |
| Antenna gain | 2.4 GHz - 5 dBi, 5 GHz - 6 dBi |
| Dimensions | 240 x 156 x 44 mm |
| Operating system | RouterOS v7, License level 6 |
| Operating temperature | -40°C to +70°C |
| Powering | |
| Number of DC inputs | 1 |
| PoE-in input Voltage | 18-57 V |
| PoE-out | Passive PoE up to 57 V (Ether5) |
| Max out per port output (input < 30 V) | 600 mA |
| Max out per port output (input > 30 V) | 500 mA |
| Max power consumption without attachments | 18 W |
| Max power consumption | 55 W |
| Included parts | • 48 V 1.35 A power adapter • UTP Flat Cable (1.5m) |
