Hikvision DS-KH6350-WTE1 KH6 Series IP-Based Indoor Station
• New UI V2.0: User friendly design
• 7-inch colorful touch screen with resolution 1024 × 600
• Standard PoE
• Stores messages and capture pictures in the TF card
• Remote unlocking via the client software or the mobile client
• Views live videos of door stations and linked cameras
| System Parameters | |
| Operating System | Embedded Linux operation system |
| ROM | 32 MB |
| RAM | 128 MB |
| CPU | Embedded processor |
| Display Parameters | |
| Screen Size | 7-inch colorful TFT screen |
| Operation Method | Capacitive touch screen |
| Type | Colorful TFT screen |
| Resolution | 1024 × 600 |
| Audio Parameters | |
| Audio Compression Standard | G.711 U, G.711 A |
| Audio Input | Built-in omnidirectional microphone |
| Audio Output | Built-in loudspeaker |
| Audio Compression Bitrate | 64 Kbps |
| Audio Quality | Noise suppression and echo cancellation |
| Volume Adjustment | Adjustable |
| Capacity | |
| Event Capacity | 200 |
| Notice Capacity | 16 |
| Linked Indoor Extensions Capacity | 5 |
| Network Parameters | |
| Communication Protocol | TCP/IP, SIP, RTSP |
| Wired Network | 10/100 Mbps self-adaptive |
| Wi-Fi Standard | Wi-Fi 802.11 b/g/n |
| Device Interfaces | |
| Alarm Input | 8-ch alarm inputs |
| Network Interface | 1 RJ-45 10/100 Mbps self-adaptive |
| RS-485 | 1 |
| TF Card | Max to 128 G |
| Alarm Output | 2 |
| Power Interface | 1 |
| General | |
| Button | 0 |
| Installation | Wall mounting, table mounting |
| Indicator | 0 |
| Weight | With package: 683 g Without package: 355 g |
| Working Temperature | -10 °C to 50 °C |
| Working Humidity | 10% to 90% |
| Dimensions | 175 mm × 113.5 mm × 21 mm |
| Application Environment | Indoor |
| Power Consumption | ≤ 8 W |
| Language | English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Portuguese, Slovak |
