TP-LINK EAP673 V1.2 AX5400 Ceiling Mount WiFi 6 Access Point
ΠΡΟΣΟΧΗ Η ΣΥΣΚΕΥΑΣΙΑ ΔΕΝ ΠΕΡΙΛΑΜΒΑΝΕΙ ΤΡΟΦΟΔΟΤΙΚΟ
| • 6-Stream Dual-Band Wi-Fi 6: 4,804 Mbps on 5 GHz, and 574 Mbps on 2.4 GHz.† • 1× 2.5G Port: Ensures fast connectivity throughout the network. • Low Latency and Interference: 160 MHz Bandwidth, MU-MIMO, OFDMA, and 1024-QAM ensure high performance for your network.‡ • Flexible Deployment and Easy Setup: Supports both 802.3at PoE and DC Power supply for flexible installation. Omada SDN for one-click setup. • Advanced Features: Supports centralized cloud management, mesh, and seamless roaming.△ • More Connections and Wider Coverage: Supports 250+ concurrent connections** and covers up to 1500 ft² (140 m²)* for reliable and extensive wireless connectivity. |
Optimized Wired Performance with 2.5G PoE+ Port
With a 2.5 Gigabit Ethernet Port, EAP673 delivers remarkable multi-gigabit performance for higher bandwidth and faster WiFi. Compatibility with 802.3at PoE is ideal for flexible deployment.
Empowering Businesses with Reliable Omada SDN Solutions
Omada’s Software-Defined Networking (SDN) solution seamlessly integrates access points (APs), managed switches, and gateways, enabling 100% centralized cloud management for a highly scalable network.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.
‡Use of Wi-Fi 6 (802.11ax), and features including 160 MHz Bandwidth, OFDMA, MU-MIMO, and 1024-QAM requires clients to also support the corresponding features. The 160 MHz bandwidth is only available on 5 GHz band and may be unavailable in some regions/countries due to regulatory restrictions.
△These features require the use of an Omada controller.
*Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.
**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
| HARDWARE FEATURES | |
| Wi-Fi Standards | 5 GHz:IEEE 802.11a/n/ac/ax 2.4 GHz:IEEE 802.11b/g/n/ax |
| Antenna | Wi-Fi •2.4 GHz: 2 × 4 dBi (peak gain), internal omnidirectional antennas •5 GHz: 4 × 5 dBi (peak gain), internal omnidirectional antennas •The down tilt angle for maximum gain：2.4G:30° to 45°; 5G:15° to 30° *Note: The gains above are the single-antenna peak gains. |
| Interfaces | • 1 x 10M/100M/1000M/2500M Multigigabit Ethernet Port (RJ45); PoE in • 1 x DC power interface: 12VDC |
| IoT | BLE5.2,1Mbps |
| Memory | Flash: 1Gbit DRAM: 4Gbit |
| Button | 1 × Reset button: Press the button for longer than 5 seconds to make the device restore to factory settings. |
| Indicator | 1 × blue system LED indicates on the front: •Power-on status •Firmware initialization or upgrade status •Uplink service status •Error status |
| Reliability | MTBF (Mean Time between Failure) 430225 hours at the operating temperature of 25°C |
| Power Supply | Input: 802.3atPoE+: 42.5 -57 V, 0.6A;12 V/2 A DC |
| Power Consumption |
•802.3at(PoE): 22.3W (for US)/20.8W (for EU), 2.4GHz radio 2×2, 5GHz radio 4×4. wired link rate can be up to 2.5Gps •Idle mode: 6.6W(PoE); 6.3W(DC) |
| Surge/Lightning Protection |
Ethernet Ports: ±2 kV |
| ESD/EMP Protection |
•Air discharge: ±8 kV •Contact discharge: ±4 kV *Note: ESD/EMP Protection means Electrostatic Discharge/Electromagnetic Pulse Protection independently. |
| Tx Power | Maximum transmit power CE (ERIP) •2.4 GHz: 20 dBm •5 GHz: 23 dBm in U-NII-1, 23 dBm in U-NII-2A, 30 dBm in U-NII-2CFCC (Conducted Power) •2.4 GHz: 22 dBm •5 GHz: 22 dBm in U-NII-1, 22 dBm in U-NII-3 *Note: MIMO combined power, excluding antenna gains. The actual transmit power depends on local laws and regulations Minimum transmit power CE (ERIP) •2.4 GHz: 7 dBm •5 GHz: 7 dBm in U-NII-1, 7 dBm in U-NII-2A, 7 dBm in U-NII-2CFCC (Conducted Power) •2.4 GHz: 4 dBm •5 GHz: 4 dBm in U-NII-1 *Note: MIMO combined power, excluding antenna gains. The actual transmit power depends on local laws and regulations |
| Environment | |
| Temperature | •Operating: 0°Cto +40°C •Storage: -40°Cto +70°C |
| Humidity | •Operating: 10% to 90% (non-condensing) •Storage: 5% to 90% (non-condensing |
| Altitude | •Storage: upto + 2000 m •Operating: up to + 2000 m |
| Unit | |
| Dimensions (W×D×H) |
•Main Unit: 220 × 220 × 32.5 mm •Shipping Unit: 280 × 259 × 91 mm |
| Weight | •Main Unit: 0.67kg •Mounting Bracket: 0.05 kg •Shipping Unit: 1.3kg |
| Mounting | •Ceiling /Wall Mounting (Kits included) •Junction Box Mounting (Kits included) •T-Bar Mounting (Kits included) |
Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 2400 – 2483,5 MHz, προβλέπει μέγιστη ισχύ εκπομπής τα 100 mW e.i.r.p.
Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
Προσοχή! Bάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στις ζώνες συχνοτήτων 5150 – 5250MHz και 5250 – 5350MHz προβλέπει μέγιστη ισχύ εκπομπής τα 200 mW e.i.r.p. και στη ζώνη συχνοτήτων 5470 – 5725MHz, προβλέπει μέγιστη ισχύ εκπομπής το 1 W e.i.r.p.
Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE Βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
