Alta Labs AP7 PRO Professional WiFi 7 Access Point
ΠΡΟΣΟΧΗ Η ΣΥΣΚΕΥΑΣΙΑ ΔΕΝ ΠΕΡΙΛΑΜΒΑΝΕΙ ΤΡΟΦΟΔΟΤΙΚΟ POE
The AP7 Professional access point from Alta Labs has been designed for environments where maximum speed and stability are expected, bringing solutions built on WiFi 7 technology that elevate wireless connectivity to a new level. With support for extremely fast connections via 10 Gbps Ethernet, the potential of modern networks can be fully utilized without bottlenecks. The tri-band architecture combined with advanced antenna design ensures not only high speeds but also excellent coverage and stable connections in densely populated networks.
Tri-band technology for maximum capacity
Advanced band splitting into 2.4 GHz, 5 GHz, and 6 GHz allows for efficient load distribution among devices. The combination of 4×4 MIMO in the 5 GHz band and 2×2 MIMO in the other bands brings an ideal balance between performance and range. Intelligent mesh features and support for seamless roaming (802.11 k/v/r) ensure smooth user movement without interruptions. The result is a stable network suitable for offices, hotels, and large commercial spaces.
Smart features and mobile connectivity without borders
Advanced management options open new usage scenarios through a cloud interface and mobile app. Passpoint (Hotspot 2.0) technology allows for automatic and secure connections for mobile devices without the need to enter a password, while carrier offload functionality transmits mobile data over the WiFi network. The integrated DPI engine provides detailed control over traffic, including application and website filtering without the need for additional hardware. All this is complemented by flexible SSID management, hotspot mode, and clear dashboards.
Elegant design and easy scalability
The modern and unobtrusive design allows for easy integration into any environment – from households to corporate installations. Powering via PoE++ simplifies installation and eliminates the need for separate power supply. Thanks to scalable cloud management, the network can be easily expanded and adjusted in real time without disrupting operations. The result is a flexible and future-proof solution that adapts to the growing demands for connectivity.
Key features
• WiFi 7 with high throughput and low latency
• 10 Gbps Ethernet port for maximum wired connection performance
• Tri-band operation (2.4 / 5 / 6 GHz) for efficient load distribution
• 4×4 MU-MIMO (5 GHz - 5760 Mbps) + 2×2 MIMO (2.4 GHz - 574 Mbps and 6 GHz - 5765 Mbps)
• Advanced mesh networking and seamless roaming (802.11 k/v/r)
• Passpoint (Hotspot 2.0) and carrier offload
• Cloud-based management and mobile application
• Integrated DPI engine for traffic filtering
• Hotspot functionality and management of multiple SSIDs
• Power over PoE++ for easy installation
Package contents
• Device
• Wall and ceiling mount
• Screws, dowels
| Specifications | |
| Mechanical | |
| Dimensions | 230 x 151.3 x 36.9 mm |
| Weight | 1.04 kg |
| Enclosure | Top Cover: Polycarbonate, Bottom Cover: Milled Aluminum |
| Mount material | Ceiling/Wall/Drop-Ceiling: Steel |
| Weatherproofing | None |
| Hardware | |
| Network Interface | Ethernet, WiFi, Bluetooth |
| Management Interface | (1) 10 Gbps RJ45 Port |
| Buttons | Reset/Factory Reset |
| LED | RGB |
| Power Method | PoE+ for up to 2.5 Gbps, PoE++ for up to 10 Gbps |
| Power Supply | PoE+ or PoE++ Enabled Network Switch, or 48V, 1.25A PoE Adapter (Optional) |
| Supported Voltage Range | 42.5-57V DC |
| Power Consumption | 35 W Max, 12 W Typical |
| MIMO | 6 GHz: 2x2, DL/UL MU-MIMO, DL/UL MU-OFDMA 5 GHz: 4x4, DL/UL MU-MIMO, DL/UL MU-OFDMA 2.4 GHz: 2x2 DL/UL MU-OFDMA Explicit TX Beam-Forming |
| Throughput Rate | 2.4 GHz: Up to 649 Mbps, 5 GHz: Up to 5.8 Gbps, 6 GHz: Up to 5.8 Gbps |
| Antenna Gain | 2.4 GHz: 4 dBi, 5 GHz: 4.75 dBi, 6 GHz: 4.5 dBi |
| Mounting | Wall, Ceiling, Drop-Ceiling, Table Top |
| Operating Temperature | -30 to 50° C |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, UK, FCC, IC (Visit Alta.inc for a Full List of Certifications) |
| Max. Transmit Power | 2.4 / 5 GHz: 30 dBm EIRP, 6 GHz: 25 dBm EIRP |
| Software | |
| Wi-Fi Standards | 802.11a/b/g/n/ac/ax/be (WiFi 4/WiFi 5/WiFi 6/WiFi 7) |
| Roaming | 802.11r/k/v |
| Wireless Security | 2.4 GHz, 5 GHz: WPA2-Personal (PSK), WPA3-Personal (SAE), WPA-Enterprise (WPA2/WPA3) 6 GHZ: WPA3 - Personal (SAE), WPA3-Enterprise (192 bit) |
| Multiple SSID | 48 (16 per Radio), Unlimited per Site |
| Ability to Limit Clients Per SSID |
Yes |
| VLAN | 802.1Q |
| Advanced QoS | 802.11e |
| Guest Traffic Isolation | Supported |
| Concurrent Clients | 500+ |
| Zero wait DFS | Yes |
| Intelligent WiFi Scheduling | Yes |
| Hotspot Functionality | Yes |
| Scalable To Stadiums | Yes |
| Seamless Per-Client Settings | VLAN, Device Type, Rate Limit, Hotspot/Schedule Exception |
| AltaPass | Yes* |
| DPI | Yes |
| Content Filtering | Yes |
| Customizable Dashboard | Yes |
| Status Snapshots | Yes |
| Supported Data Rates | |
| 802.11a/g | 6 Mbps to 54 Mbps |
| 802.11b | 1 Mbps to 11 Mbps |
| 802.11n | 6.5 Mbps to 600 Mbps (Up to MCS 31) |
| 802.11ac | 6.5 Mbps to 3.4 Gbps (Up to MCS 9) |
| 802.11ax | 2.4 GHz: Up to 574 Mbps, 5/6 GHz: 6.5 Mbps to 5.8 Gbps (Up to MCS 13) |
| 802.11be | 2.4 GHz: Up to 649 Mbps, 5/6 GHz: Up to 5.8 Gbps |
* Password-based assignment is not supported currently in 6 GHz band but still per-MAC assignment is supported.
Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 2400 – 2483,5 MHz, προβλέπει μέγιστη ισχύ εκπομπής τα 100 mW e.i.r.p.
Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
Προσοχή! Bάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στις ζώνες συχνοτήτων 5150 – 5250MHz και 5250 – 5350MHz προβλέπει μέγιστη ισχύ εκπομπής τα 200 mW e.i.r.p. και στη ζώνη συχνοτήτων 5470 – 5725MHz, προβλέπει μέγιστη ισχύ εκπομπής το 1 W e.i.r.p.
Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE Βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 5945 – 6425 MHz ορίζεται στο παρόν έγγραφο. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017
