Ubiquiti U-POE++ PoE Gigabit PoE Injector, 48V/1.25A
Κωδικός προϊόντος:
U-POE++
37,00 €
(Περιλαμβάνει ΦΠΑ 24%)
Τιμή χωρίς ΦΠΑ:
29,84 €
Άμεσα διαθέσιμο
Ubiquiti U-POE++ PoE Gigabit PoE Injector, 48V/1.25A
Υπολογισμός κόστους μεταφορικών:
Ποσότητα
Περιγραφή
Χαρακτηριστικά
Λήψεις
Περιγραφή
U-POE++ is a high-quality Gigabit PoE injector with one PoE output port for powering devices with voltage level of 48V with a maximum output power of 60W, which is sufficient for the energy-intensive devices. The power supply is conducted on all the wires 1,2,4.5 (+) and 3,6,7.8 (-). Of course, the source also includes protection against electrical overvoltage. A 3-pin power cord is included.
• Delivers up to 60W of PoE+
• Even more power for UA Hub, G4 PTZ, and other PoE++ devices
• Surge, peak pulse, and overcurrent protection
• Contains RJ45 data input, AC cable with earth ground, and PoE++ output
• LED indicator for status monitoring
Χαρακτηριστικά
| Specifications | |
| Dimensions | 106 x 63 x 34 mm |
| Weight | 210 g |
| Output Voltage | 48V DC @ 1.25A |
| LAN Activity Indicator | No |
| Gigabit LAN Port | Yes |
| Remote Reset Capability | No |
| Reset Button | No |
| Rated Voltage | 100-240VAC @ 50/60Hz |
| Input Current | 1.3A @ 120V AC 0.75A @ 230V AC |
| Inrush Current | <100A peak @ 120V AC <200A peak @ 230V AC |
| Efficiency | 85+% |
| Output Ripple | 1% max. |
| Switching Frequency | 65 kHz |
| Line Regulation | ≤ 1% |
| Load Regulation | ≤ 3% |
| 2-pair powering | No |
| 4-pair powering | Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-) |
| AC Connector | IEC-320 C6 |
| Data IN / POE | RJ45 Shielded Socket |
| Surge Protection | Difference and Common Mode |
| Clamping Protection | 11V Data, 60V Power |
| Max. Surge Discharge | 1500A (8/20 µs) Power |
| Peak Pulse Current | 36A (10/1000 µs) Data |
| Shunt capacitance | <5 pF data |
| Response time | <1 ns |
| Power method | Universal AC input, 100—240V AC, 50/60Hz, (48V@ 1.25A) |
| Power supply | AC/DC |
| Supported voltage range | 100—240V AC |
| Max. PoE+ wattage per port by PSE | 60W |
| Operating temperature | 0 to 40° C |
| Storage temperature | -30 to 70°C |
| Operating humidity | 10 to 95% noncondensing |
| Certifications | CE, FCC, IC, UL, UKCA, KC, CCC, KC, RoHS |
Λήψεις
