Ubiquiti UDB Unifi Device Bridge, Wireless Bridge with PoE Out, 5GHZ
Ubiquiti UDB Unifi Device Bridge, Wireless Bridge with PoE Out, 5GHZ
This plug-and-play 5 GHz wireless bridge enables point-to-point connection to another Bridge device. It features one GbE RJ-45 PoE-Out port to power another device, such as cameras and other devices. The bridge itself is powered through a standard network cable.
- (1) GbE PoE-Out port providing up to 15W power.
- 5 GHz band with a data transfer rate of up to 867 Mbps.
- Compatible with UniFi Protect PoE cameras, UniFi Talk phones, and other IoT devices.
Package Contents
- Device
- Mounting materials
- External antenna
- Power cable
| Specifications | |
| Overview | |
| Dimensions | 130 x 55 x 34 mm |
| WiFi Standard | WiFi 5 |
| Spatial Streams | 2 |
| Mounting Locations | Wall, table |
| Mounting | Wall (Included) |
| Power Method | 100—240V AC, 0.45A Max., 50/60 Hz |
| Performance | |
| MIMO | 5 GHz:2 x 2 |
| Max. Data Rate | 5 GHz:866.7 Mbps (BW80) |
| Antenna Gain | 5 GHz:Internal: 5 dBi External omni: 4 dBi, 360° x 30° |
| Max. TX Power | 5 GHz:21 dBm |
| Supported Data Rates | 802.11ac: (WiFi 5) 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) 802.11n:6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Wireless Security | WPA2 AES |
| Hardware | |
| Max. Power Consumption | 25W (AC input) 10W (Excluding PoE output) |
| Supported Voltage Range | 100—240V AC |
| Networking Interface | (1) GbE RJ45 port |
| Antennas | (1) Internal antenna (1) RP-SMA connector for external omni-antenna |
| Management | WiFi |
| Channel Bandwidth | 20/40/80 (MHz) |
| Weight | 200 g |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| Button | (1) Factory-reset |
| LEDs | System: (4) Blue: signal (1) White/blue: indicator |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
| Operating Frequency | US/CA: U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz Worldwide: 5150 - 5875 MHz |
| Ambient Operating Temperature | -10 to 40° C |
| Ambient Operating Humidity | 5 to 95% noncondensing |
Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5150 – 5250MHz and 5250 – 5350MHz, provides for a maximum transmit power of 200 mW e.i.r.p. and in the frequency band 5470 – 5725MHz, provides for a maximum transmit power of 1 W e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.
