TP-LINK EAP725-WALL V1.2 BE3600 Wall Plate WiFi 7 Access Point
ΠΡΟΣΟΧΗ! Στην συσκευασία δεν συμπεριλαμβάνεται τροφοδοτικό!
| • BE3600 Wi-Fi 7 (2882 Mbps on 5 GHz + 688 Mbps on 2.4 GHz).† • 1× 2.5G PoE input port + 1× 2.5G pass-through port + 2× Gigabit RJ45 downlink ports. • 160 MHz bandwidth enables many more simultaneous transmissions.‡ • MLO and Multi-RUs ensure the high performance of your network.‡ • Advanced Functions: Centralized management, Mesh, and Seamless Roaming.△ |
Optimized Wired Performance with 2.5G PoE Ports
With 2.5G PoE input and pass-through ports, along with two Gigabit RJ45 ports, enjoy high-speed data transfers and connect multiple devices to your gigabit network. Wired devices, such as IP Phones, can be powered without the need for additional electrical cables.
The PoE pass-through feature requires an 802.3at/bt PoE input. If the power consumption of the AP's downstream device exceeds 7W, the AP needs an 802.3bt input.
Seamless Integration into the Omada SDN
Remotely manage your access points, switches, and routers across multiple sites — all from a single interface.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. The 160 MHz bandwidth is only available on the 5GHz band. It may be unavailable in some regions/countries due to regulatory restrictions. Actual wireless data throughput, wireless coverage, and connected devices are not guaranteed and will vary as a result of internet service provider factors, network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
‡Use of Wi-Fi 7 (802.11be) and features including 160 MHz Bandwidth, 4K-QAM, Multi-RUs, OFDMA and MU-MIMO requires clients to also support the corresponding features.
**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
§Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.
△Omada Mesh, Seamless Roaming, Captive Portal, and Cloud Access require the use of an Omada SDN controller. Please refer to the User Guides of Omada SDN controllers for configuration methods.
| HARDWARE FEATURES | |||||||||||||
| Main Design |
|||||||||||||
| Wi-Fi Standards | 5 GHz:IEEE 802.11a/n/ac/ax/be 2.4 GHz:IEEE 802.11b/g/n/ax/be |
||||||||||||
| Antenna |
Wi-Fi 2.4 GHz: 2 × 4dBi (peak gain), Internal dipole antenna IoT Bluetooth: 1 × 1.5dBi (peak gain), internal omnidirectional antennas |
||||||||||||
| Interfaces | 1 x 10M/100M/1000M/2.5Gbps Multigigabit Ethernet Port (RJ45); PoE In 1 x 10M/100M/1000M/2.5Gbps Multigigabit Ethernet Port (RJ45); PoE Out 2x 10M/100M/1000M Gigabit Ethernet Port (RJ45) |
||||||||||||
| IoT | BLE 5.2, 1Mbps | ||||||||||||
| Memory | Flash: 1024Mbit DRAM: 4096Mbit |
||||||||||||
| Button | 1 × Reset button: Press the button for longer than 5 seconds to make the device restore to factory settings. 1x LED Button |
||||||||||||
| Indicator | 1 × white LED on the front Power-on status Firmware initialization or upgrade status Error status |
||||||||||||
| Reliability |
MTBF (Mean Time between Failure) 372121H@25°C; 162774H@40°C |
||||||||||||
| Power Supply |
Input 1*802.3at PoE+: 42.5 - 57 V ⎓ 0.6A Output Passive PoE: Polarity1/2(-), 3/6(+) |
||||||||||||
| Surge/Lightning Protection |
Ethernet Ports: ±4 kV | ||||||||||||
| ESD/EMP Protection |
Air discharge: ±8 kV Contact discharge: ±4 kV Note: ESD/EMP Protection means Electrostatic Discharge/Electromagnetic Pulse Protection independently. |
||||||||||||
| Tx Power |
Maximum transmit power CE (EIRP) Minimum transmit power CE (EIRP) Adjustable power increment |
||||||||||||
| Environment |
Temperature Operating: 0°Cto +40°C Humidity Operating: 10% to 90% (non-condensing) Altitude Storage: upto + 2000 m |
||||||||||||
| Unit |
Dimensions (W×D×H) Main Unit: 143 × 86 × 40 mm Weight Main Unit: 0.36kg Mounting Wall Plate Mounting (Screwsincluded) |
||||||||||||
| Maximum Power Consumption |
|
||||||||||||
Προσοχή! Βάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στη ζώνη συχνοτήτων 2400 – 2483,5 MHz, προβλέπει μέγιστη ισχύ εκπομπής τα 100 mW e.i.r.p.
Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
Προσοχή! Bάσει της ισχύουσας Ελληνικής Νομοθεσίας, του Ε.Κ.Κ.Ζ.Σ. και των όσων προβλέπει το Π.Δ. 98/2017 η νόμιμη χρήση του προϊόντος αυτού στις ζώνες συχνοτήτων 5150 – 5250MHz και 5250 – 5350MHz προβλέπει μέγιστη ισχύ εκπομπής τα 200 mW e.i.r.p. και στη ζώνη συχνοτήτων 5470 – 5725MHz, προβλέπει μέγιστη ισχύ εκπομπής το 1 W e.i.r.p.
Στην ισχύ αυτή συνυπολογίζεται η ισχύς εξόδου του πομπού και το κέρδος της κεραίας. Αρμόδια για την εποπτεία του φάσματος είναι η E.E.T.T.
Το προϊόν αυτό είναι εφοδιασμένο με σήμα συμμόρφωσης CE Βλ. Π.Δ. 98/2017
Το προϊόν αυτό προορίζεται για χρήση σε εσωτερικούς χώρους.
