- Sound Decibel: 1 meterSingle frequency point 110 dBA(Maximum value)Single frequency point 106 dBA(Average value)
- IP55 protective level
- Sound and LED flash indication separately
- Controlled by PGM/BELL port
- Three types of alarm sounds are available: fire alarm, panic alarm, and intrusion alarm.
- Triggered by Positive / Negative
- Tamper Alarm & Cut Wire Alarm
Περιγραφή
Χαρακτηριστικά
Λήψεις
Περιγραφή
Χαρακτηριστικά
| Hardware features |
|
| Tamper-Proof |
Front cover tamper-proof |
| Audio | |
| Sound pressure | 110dB/1m（Maximum Value |
| Electrical characteristics | |
| Power supply |
9 to 16VDC |
| Typical voltage | 12 VDC |
| Power consumption | Maximum current: 180mA@12V DC |
| Operation humidity | 10％～90％ |
| Operation temperature | -20℃～＋60℃ |
| General | |
| IP rate | IP55 |
| Dimension (W x H x D) | 221x215x51mm |
| Shell material | PC+ABS |
| Color | Red |
| Weight | 475g |
