Ubiquiti UF-WiFi U Fiber WiFi, GPON CPE
Product Code:
UF-WiFi
Manufacturer Ubiquiti
Sales price:
95,00 €(Includes 24% VAT)
Sales price without TAX:76,61 €
Product Availability:
Show Shipping Cost:
- Description
- Specifications
- Downloads
- Reviews
Ubiquiti UF-WiFi U Fiber WiFi, Gigabit Passive Optical Network CPE
GPON Optical Network Unit
UFiber WIFI is a robust, high‑performance GPON CPE that offers routing, four LAN ports, and Wi-Fi. It is powered by 24V passive PoE or a 24V, 0.5A power adapter.
Features
• (1) GPON WAN Port and (4) Gigabit Ethernet Ports
• 802.11n Wi-Fi
• 7W Max. Power Consumption
| Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p. At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C. This product is CE marked, P.D. 98/2017 This product is intended for outdoor use. |
| Warranties - Returns: | |
| Money Return: | Repair - Replacement: |
| 20 days | 12 months |
| Specifications | |
| Dimensions | 126.34 x 126.09 x 31.65 mm |
| Weight | 190 g |
| Networking Interface Speeds GPON WAN, ITU G.984 GbE LAN Wi-Fi |
2.488 Gbps Downstream 1.244 Gbps Upstream 10/100/1000 Mbps 300 Mbps |
| Management Interface | In-Band Ethernet/PON |
| Normal Optical Power Range | TX (Class B+): 1.5 to 5 dBm RX: -28 to -8 dBm |
| Power Method | DC Jack, 24VDC 24V Passive PoE (Pins 4, 5+; 7, 8-) |
| Power Supply | 100-240VAC / 50-60 Hz Universal AC/DC Power Adapter: 24V / 0.5A |
| Max. Power Consumption | 7W |
| Supported Voltage Range | 20 to 28V |
| Processor Specs | MIPS, 900 MHz |
| Memory Information | 256 MB DDR |
| Buttons | (1) Reset |
| Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
