• New UI V2.0: User friendly design
• 7-inch colorful touch screen with resolution 1024 × 600
• Standard PoE
• Stores messages and capture pictures in the TF card
• Remote unlocking via the client software or the mobile client
• Views live videos of door stations and linked cameras

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for indoor use.

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	36 months

System Parameters
Operating System	Embedded Linux operation system
ROM	32 MB
RAM	128 MB
CPU	Embedded processor
Display Parameters
Screen Size	7-inch colorful TFT screen
Operation Method	Capacitive touch screen
Type	Colorful TFT screen
Resolution	1024 × 600
Audio Parameters
Audio Compression Standard	G.711 U, G.711 A
Audio Input	Built-in omnidirectional microphone
Audio Output	Built-in loudspeaker
Audio Compression Bitrate	64 Kbps
Audio Quality	Noise suppression and echo cancellation
Volume Adjustment	Adjustable
Capacity
Event Capacity	200
Notice Capacity	16
Linked Indoor Extensions Capacity	5
Network Parameters
Communication Protocol	TCP/IP, SIP, RTSP
Wired Network	10/100 Mbps self-adaptive
Wi-Fi Standard	Wi-Fi 802.11 b/g/n
Device Interfaces
Alarm Input	8-ch alarm inputs
Network Interface	1 RJ-45 10/100 Mbps self-adaptive
RS-485	1
TF Card	Max to 128 G
Alarm Output	2
Power Interface	1
General
Button	0
Installation	Wall mounting, table mounting
Indicator	0
Weight	With package: 683 g Without package: 355 g
Working Temperature	-10 °C to 50 °C
Working Humidity	10% to 90%
Dimensions	175 mm × 113.5 mm × 21 mm
Application Environment	Indoor
Power Consumption	≤ 8 W
Language	English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Portuguese, Slovak
