• 8 10/100/1000Mbps RJ45 ports • Plug and play, with no configuration required • Durable metal casing of superior quality and professional appearance • Intelligent management via a web user interface and downloadable utility • Green technology reduces power consumption |
Link Your Devices, Create Convenient Business
The 8-Port Gigabit Easy Smart Desktop Switch provides an easy way to expand your wired network. Deal with your business quickly and easily, whether you are at home or in the office.
Easy to Use
1) Plug In
2) Connect Devices
3) Enjoy
Gigabit Ports for Maximum Speed
8 non-blocking 10/100/1000 Mbps ports make it possible to transfer large, bandwidth-intensive files with no interference.
More Features, More Choices
QoS for a Lag-Free Experience Ensures smooth traffic for latency sensitive applications, such as voice and video.
IGMP Snooping for Multicast Optimization Ensures a better network experience, especially for applications like IPTV, by optimizing multimedia traffic delivery.
VLAN for Security Helps to create network with higher security and better overall performance by dividing network into smaller groups.
Management Made Easy
TL-SG108E offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG108E offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.
Durable Metal Casing
The interior components of TL-SG108E are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG108E delivers switching performance you can depend on.
Go Green with Your Ethernet
TP-Link’s latest generation of Easy Smart Switches make use of innovative energy-saving technologies. Power consumption automatically adjusts according to link status and cable length, allowing you to expand your network while minimizing your carbon footprint. Save the planet and lower your energy bills — it’s a win-win!
Warranties - Returns: | |
Money Return: | Repair - Replacement: |
20 days | 60 months |
SPECIFICATIONS | |
GENERAL | |
Interface | 8 10/100/1000Mbps RJ45 |
Mounting | Desktop/Wall Mounting |
PERFORMANCE | |
Forwarding Rate | 11.9Mpps |
Switching Capacity | 16Gbps |
MAC Address Table | 4K |
Packet Buffer Memory | 1.5Mbit |
Jumbo Frame | 16KB |
PHYSICAL & ENVIRONMENT | |
Power Supply | External Power Adapter (9V/0.6A) |
Max Power Consumption | 2.71 W (220 V/50 Hz) |
Max Heat Dissipation | 9.25 BTU/h |
Dimensions(WxDxH) | 158 x 101 x 25 mm |
Fan Quantity | Fanless |
Operating Temperature | 0 °C–40 °C (32 °F–104 °F) |
Storage Temperature | -40 °C–70 °C (-40 °F–158 °F) |
Operating Humidity | 10%–90%RH, non-condensing |
Storage Humidity | 5%–90%RH, non-condensing |
Certification | CE, FCC |
SOFTWARE FEATURES | |
Quality of Service | • 4 Priority Queues • 802.1p/DSCP QoS • Rate Limit • Storm Control |
L2 Features | • IGMP Snooping • Static Link Aggregation - TL-SG108E: up to 2 groups, 4 ports per group • Port Mirroring • Loop Prevention |
VLAN | • 32 VLANs (out of 4K VLAN IDs) • MTU/Port/802.1Q VLAN |
Management | • Easy smart configuration utility • Web-based Graphic User Interface (GUI) |
OTHERS | |
Package Contents | TL-SG108E Power Adapter Installation Guide Rubber Feet |
