• BE19000 Tri-Band Wi-Fi 7: 11520 Mbps (6 GHz) + 5760 Mbps (5 GHz) + 1376 Mbps (2.4 GHz). Buffering will no longer be a problem.
• Clear 6 GHz Band: Brings cleaner and wider band resources.
• 2× 10G Port: Unlock the full potential of Wi-Fi 7.
• 320 MHz Bandwidth: enables many more simultaneous transmissions.
• Multi-Link Operation and Multi-RUs ensure the high performance of your network.
• Advanced Functions：Centralized management, mesh, and AI roaming.

Software Defined Networking (SDN) with Cloud Access
Omada Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network——all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

Hassle-Free Centralized Cloud Management
100% centralized cloud management of the whole network from different sites——all controlled from a single interface anywhere, anytime.

Zero-Touch Provisioning for Efficient Deployment
Omada zero-touch provisioning allows remotely deployment and configuration of multi-site networks, so there's no need to send out an engineer for on-site configuration. The Omada Cloud ensures efficient deployment with lower costs.

Assign Different Management Roles
Multi-user privilege assignment is available to increase management efficiency and security. Multi-person management, multi-level permissions, and the ability to add admins as needed, enable flexible network operation and maintenance.

Easy and Intelligent Network Monitoring
The easy-to-use dashboard makes it easy to see your real-time network status; check network usage and traffic distribution; receive network condition logs, abnormal event warnings, and notifications; or even track key data for better business results. Network topology helps IP admins quickly see and troubleshoot connection at a glance.

Multiple Factors Guarantee Higher Reliability
Higher reliability of cloud service is guaranteed with 99.9% SLA availability, 24/7 automated fault detection, geographically isolated backup servers, and reliable product quality. Your network functions even if management traffic is interrupted.

Reliable Connections Even with High-Density Clients
Equipped with enterprise chipsets, dedicated antennas, advanced RF functions, auto channel selection, and power adjustment, Omada APs have high concurrency capacities for remarkable performance in high-density environments.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for outdoor use.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5150 – 5250MHz and 5250 – 5350MHz, provides for a maximum transmit power of 200 mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for outdoor use.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5945 – 6425 MHz defined in this document, Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	24 months

Main Design
LAN Interfaces	2x 10Gbps Ethernet Port
Wi-Fi Standards	IEEE 802.11 a/b/g/n/ac/ax/be
Maximum Data Rate	1376 Mbps (2.4 GHz)+5760 Mbps (5 GHz)+11520 Mbps (6 GHz)
Wireless Client Capacity	640
Antennas	2.4 GHz: 4 x 4 dBi 5 GHz: 4 x 5.5 dBi 6 GHz: 4 x 5 dB
Bluetooth	Supported
Transmit Power	• CE: <20 dBm (2.4GHz, EIRP); <23 dBm (5GHz band 1&band 2, EIRP);<30 dBm(5GHz band 3, EIRP); < 23 dBm (6 GHz EIPR) • FCC: <28 dBm (2.4GHz); <28 dBm (5G band 1&band 4);<24 dBm(5G band 2&band 3); < 28dBm (6 GHz)
Reception Sensitivity	2.4GHz: 11ax HE20 MCS0:-96dBm; 11ax HE20 MCS11:-66.5dBm 11ax HE40 MCS0:-93dBm; 11ax HE40 MCS11:-64dBm 5GHz: 11be EHT20 MCS0:-94dBm; 11be EHT20 MCS11:-63dBm 11be EHT40 MCS0:-90.5dBm; 11be EHT40 MCS11:-60dBm 11be EHT80 MCS0:-88dBm; 11be EHT80 MCS11:-57.5dBm 11be EHT160 MCS0:-85dBm; 11be EHT160 MCS11:-55.5dBm 11be EHT320 MCS0:-82dBm; 11be EHT320 MCS11:-53dBm 6GHz: 11be EHT20 MCS0:-93dBm; 11be EHT20 MCS11:-63dBm 11be EHT40 MCS0:-90dBm; 11be EHT40 MCS11:-60dBm 11be EHT80 MCS0:-87.5dBm; 11be EHT80 MCS11:-57.5dBm 11be EHT160 MCS0:-84dBm; 11be EHT160 MCS11:-55dBm 11be EHT320 MCS0:-81.5dBm; 11be EHT320 MCS11:-52.5dBm
Centralized Management
Omada Software Controller	Yes
Omada Hardware Controller	Yes
Omada APP	Yes
Security
Captive Portal Authentication	Yes
Access Control	Yes
Maximum number of MAC Filter	4000
Wireless Isolation between Clients	Yes
VLAN	Yes
Rogue AP Detection	Yes
Wireless Encryption	WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE
Wireless Function
Multiple SSIDs	24 (8 on each band)
Channel	2G:1 - 13 5G: 36,40,44,48,52,56,60,64,100,104,108, 112,116,120,124,128,132,136,140 6G: 33,37,41,45,49,53,57,61,65,69,73,77,81,85,89,93
Enable/Disable Wireless Radio	Yes
Enable/Disable SSID Broadcast	Yes
Guest Network	Yes
Automatic Channel Assignment	Yes
Transmit Power Control	Adjust transmit Power on dBm
QoS (WMM)	Yes
Seamless Roaming	Yes
Mesh	Yes
Beamforming	Yes
MU-MIMO	4x4 MU-MIMO DL/UL
OFDMA	UL/DL OFDMA
Rate Limit	Based on SSID/Client
Load Balance	Yes
Airtime Fairness	Yes
Band Steering	Yes
RADIUS Accounting	Yes
MAC Authentication	Yes
Reboot Schedule	Yes
Wireless Schedule	Yes
Wireless Statistics	Yes
Static IP/Dynamic IP	Yes
Support Data Rates
802.1be	8.6Mbps to 11520 Mbps (MCS0-MCS13,NSS=1-4 ETH20/40/80/160/240/320)
802.11ax	8.6Mbps to 4804 Mbps (MCS0-MCS11,NSS=1-4 HE20/40/80/160)
802.11ac	6.5Mbps to 4334 Mbps (MCS0-MCS11,NSS=1-4 VHT20/40/80/160)
802.11n	6.5Mbps to 600 Mbps (MCS0-MCS7,NSS=1-4 HT20/40)
802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b	1, 2, 5.5, 11 Mbps
802.11a	6, 9, 12, 18, 24, 36, 48, 54 Mbps
Management
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
Web-based Management	Yes
SNMP	v1, v2c, v3
SSH	Yes
Restore & Backup	Yes
Firmware update via Web	Yes
NTP	Yes
System Log	Yes
Email Alerts	Yes
Physical & Environment
Power Supply	802.3bt PoE or 12V/4.5A DC
Maximum Power Consumption	34W (for DC), 39W(for PoE)
Reset	Yes
Mounting	Ceiling / Wall mouting (Kits included)
Others
Certifications	CE, FCC, RoHS, IC
Dimensions (W x D x H)	280 x 280 x 46.5 mm
Net Weight	1384.6 g
Enclosure Material / Rack Material	Top cover: PC Bottom shell: aluminum alloy Mounting rack: stainless steel
Lightning Protection	Air discharge: ±8kV Contact discharge: ±4kV Common mode: 10/700: ±4kV
Environment	Operating Temperature: 0 °C–40 °C Storage Temperature: -40 °C–70 °C Operating Humidity: 10%–90% non-condensing Storage Humidity: 5%–90% non-condensing
