Ceiling-mounted WiFi 7 AP with 6 spatial streams and 6 GHz support for interference-free WiFi in demanding, large-scale environments.

Features:
• WiFi 7 tri-radio with 6 GHz
• 6 spatial streams
• 140 m² coverage
• 300+ connected devices
• Powered using PoE+
• 2.5 GbE uplink

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 2400 – 2483,5 MHz, provides for a maximum transmit power of 100mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for outdoor use.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5150 – 5250MHz and 5250 – 5350MHz, provides for a maximum transmit power of 200 mW e.i.r.p.
At this maximum power the output power of the transmitter and the gain of the antenna are both taken into account. Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017
This product is intended for outdoor use.

Caution! According to current Greek Legislation, of N.F.B.A.R. and the provisions of the P.D. 98/2017 the lawful use of this product in the frequency band 5945 – 6425 MHz defined in this document, Responsible for spectrum surveillance is H.T.P.C.
This product is CE marked, P.D. 98/2017

Warranties - Returns:
Money Return:	Repair - Replacement:
20 days	12 months

Specifications
Mechanical
Dimensions	Ø206 x 46 mm
Weight	680g
Enclosure Material	Polycarbonate, metal
Mount material	Mounting bracket: stainless steel (SUS304) Backing plate: galvanized steel (SGCC)
Hardware
Management Interfaces	Ethernet
Networking Interface	(1) 2.5 GbE RJ45 port
Button	Factory Reset
LEDs	White/Blue
Power Method	PoE+
Power Supply	UniFi PoE switch
Supported Voltage Range	44 to 57V DC
Max. Power Consumption	21W
Max. TX Power 2.4 GHz 5 GHz 6 GHz	22 dBm 26 dBm 23 dBm
MIMO 2.4 GHz 5 GHz 6 GHz	2 x 2 2 x 2 2 x 2
Throughput Speeds 2.4 GHz 5 GHz 6 GHz	688 Mbps 2882 Mbps 5765 Mbps
Antenna Gain 2.4 GHz 5 GHz 6 GHz	4 dBi 6 dBi 5.8 dBi
Mounting	Wall/ceiling (included)
Operating Temperature	-30 to 60° C
Operating Humidity	5 to 95% Noncondensing
Certifications	CE, FCC, IC
Software
Wi-Fi Standards	802.11a/b/g/n/ac/ax/be
Wireless Security	WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID	8 per Radio
VLAN	802.1Q
Advanced QoS	Per-User Rate Limiting
Guest Traffic Isolation	Supported
Concurrent Clients	300+
Supported Data Rates
802.11a	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b	1, 2, 5.5, 11 Mbps
802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n	6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (Wi-Fi 5)	6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (Wi-Fi 6)	7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11be (Wi-Fi 7)	7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
Application Requirements
UniFi Network	Version 8.0.7 and later
UniFi OS	Version 3.2 and later
